Standard configuration
COLOUR TEMPERATURE
4000 K
CONTROL
DIM DALI / CLO
MATERIAL COLOUR
white
7
LIGHT OPTIC COVER
microprismatic (UGR < 19)
Options on request
FORM
other configurations on page 119
34
1535
1535
15
34
1535
2725
15
TASK angular suspended
TASK long angular suspended
SYS. POWER
COLOUR TEMP.
LUM. FLUX
ORDER CODE
252 W
4000 K
18680 / 12040 lm
0 5 9 - 5 2 8 3 6 3 7 P
SYS. POWER
COLOUR TEMP.
LUM. FLUX
ORDER CODE
360 W
4000 K
26700 / 17200 lm
0 5 9 - 5 2 8 4 6 3 7 P
DIRECT / INDIRECT POWER
DIRECT / INDIRECT POWER
UGR
< 19
UGR
< 19
220-240 V
220-240 V
1 ADDR.
1 ADDR.
microprismatic
direct / indirect power
LIGHT DISTRIBUTION
60°
120°
60°
120°
90°
90°
pending
pending
pending
pending
500 lx
400 lx
Technical data
TASK long angular, 360 W, 4000 K,
direct / indirect power
ROOM VALUES
Room dimensions
5.4 × 4 × 2.8 m
Reflection factor
0.7 | 0.5 | 0.2
Maintenance factor
0.8
Suspension height
2.25 m
CALCULATION SURFACE
Surface dimensions
3.2 × 1.2 m
Surface height
0.75 m
Average illuminance (Em)
> 500 lx
Uniformity (U0)
> 0.6
GLARE EVALUATION
Table Classification X=4H | Y=8H | S=0.25H
UGR transversal
< 19
UGR axial
< 19
65° < 3000 cd/m²
PLAFONIERE E APPARECCHI A SOSPENSIONE
НАКЛАДНЫЕ И ПОДВЕСНЫЕ СВЕТИЛЬНИКИ
407
