MICRO INCASSI MICRO RECESSED SPOTS
MICRO INCASSI MICRO RECESSED SPOTS
BBTT coin
ø 76 mm
Foro d’incasso
Recessed hole
DRIVER CONSIGLIATI - RECOMMENDED DRIVERS
644759-1
DRIVER ON-OFF
15W
IP20
350mA
645984
DRIVER ON-OFF
15W
IP40
350mA
CODICE - CODE
BEAM
W
LM
K
V
CRI
KG
BI
INCASSI FISSI - FIXED RECESSED
2815C-LBC-15
15°
12,9W
1040
3000
350mA
>90
0,3
NE
2816C-LBC-15
CR
2817C-LBC-15
ORO
2818C-LBC-15
BI
2815C-LBC-24
24°
12,9W
1430
NE
2816C-LBC-24
CR
2817C-LBC-24
ORO
2818C-LBC-24
BI
2815C-LBC-40
40°
12,9W
1360
NE
2816C-LBC-40
CR
2817C-LBC-40
ORO
2818C-LBC-40
BI
2815C-LBN-15
15°
12,9W
1120
4000
NE
2816C-LBN-15
CR
2817C-LBN-15
ORO
2818C-LBN-15
BI
2815C-LBN-24
24°
12,9W
1510
NE
2816C-LBN-24
CR
2817C-LBN-24
ORO
2818C-LBN-24
BI
2815C-LBN-40
40°
12,9W
1430
NE
2816C-LBN-40
CR
2817C-LBN-40
ORO
2818C-LBN-40
FISSO - FIXED RECESSED
0÷20 mm
ACCESSORI - ACCESSORIES
BI
116
ANELLO DI COMPENSAZIONE
COMPENSATION RING
IN Ø 75 mm OUT Ø 150 mm
117
ANELLO DI COMPENSAZIONE
COMPENSATION RING
IN Ø 80 mm OUT Ø 160 mm
• Incasso in pressofusione di alluminio.
• Verniciatura in polveri di poliestere.
• Recessed trim of die-cast aluminium.
• Polyester powder coating.
BBTT coin SEMIORIENTABILE - SEMI-ADJUSTABLE
ø 82 mm
Foro d’incasso
Recessed hole
DRIVER CONSIGLIATI - RECOMMENDED DRIVERS
644759-1
DRIVER ON-OFF
15W
IP20
350mA
645939
DRIVER DIM DALI
7÷26W
IP20
150÷700mA
CODICE - CODE
BEAM
W
LM
K
V
CRI
KG
BI
INCASSI SEMIORIENTABILI - SEMI-ADJUSTABLE RECESSED
2825C-LBC-15
15°
12,9W
1040
3000
350mA
>90
0,3
NE
2826C-LBC-15
CR
2827C-LBC-15
ORO 2828C-LBC-15
BI
2825C-LBC-24
24°
12,9W
1430
NE
2826C-LBC-24
CR
2827C-LBC-24
ORO 2828C-LBC-24
BI
2825C-LBC-40
40°
12,9W
1360
NE
2826C-LBC-40
CR
2827C-LBC-40
ORO 2828C-LBC-40
BI
2825C-LBN-15
15°
12,9W
1120
4000
NE
2826C-LBN-15
CR
2827C-LBN-15
ORO 2828C-LBN-15
BI
2825C-LBN-24
24°
12,9W
1510
NE
2826C-LBN-24
CR
2827C-LBN-24
ORO 2828C-LBN-24
BI
2825C-LBN-40
40°
12,9W
1430
NE
2826C-LBN-40
CR
2827C-LBN-40
ORO 2828C-LBN-40
SEMIORIENTABILE - SEMI-ADJUSTABLE
0÷20 mm
ACCESSORI - ACCESSORIES
BI
116
ANELLO DI COMPENSAZIONE
COMPENSATION RING
IN Ø 75 mm OUT Ø 150 mm
117
ANELLO DI COMPENSAZIONE
COMPENSATION RING
IN Ø 80 mm OUT Ø 160 mm
• Incasso in pressofusione di alluminio.
• Verniciatura in polveri di poliestere.
• Recessed trim of die-cast aluminium.
• Polyester powder coating.
