Yori Linear Track
738
920 | Continuous line (Central module)
Risk 0 1.0 Kg IP20
850°
CB
51
920
36
Code example:
0 . D
F650 . HW 12
Track/Binario: p.707
Finishes: p.724
Photometric data:
www.reggiani.net
26 W
MID POWER LED
Lumen delivered up to 3570 lm / Lumen maintenance: L70 B50=50,000h
Driver
Diffuser
Beam width
Version
LED
K
CRI
lm
SDCM
Finishes
0
On/Off
D
Opal
77°
F650 920mm
HW
2700
>90
3350
<3
12
L
Prismatic
85°
HQ
3000
>90
3640
<3
31
X
Ribbed
78°
WW
3000
>80
4185
<3
Q
Anti-glare louvre
60°
NN
4000
>80
4630
<3
V
Opal, U-Shape
104°
LED nominal lumen
460 | Continuous line (Central module)
Risk 0 0.80 Kg IP20
850°
CB
51
460
36
Code example:
0 . D
F620 . HW 12
Track/Binario: p.707
Finishes: p.724
Photometric data:
www.reggiani.net
13 W
MID POWER LED
Lumen delivered up to 1870 lm / Lumen maintenance: L70 B50=50,000h
Driver
Diffuser
Beam width
Version
LED
K
CRI
lm
SDCM
Finishes
0
On/Off
D
Opal
77°
F620 460mm
HW
2700
>90
1750
<3
12
L
Prismatic
85°
HQ
3000
>90
1900
<3
31
X
Ribbed
78°
WW
3000
>80
2190
<3
Q
Anti-glare louvre
60°
NN
4000
>80
2430
<3
V
Opal, U-Shape
104°
LED nominal lumen
1380 | Continuous line (Central module)
Risk 0 1.20 Kg IP20
850°
CB
1380
36
51
Code example:
0 . D
F670 . HW 12
Track/Binario: p.707
Finishes: p.724
Photometric data:
www.reggiani.net
38 W
MID POWER LED
Lumen delivered up to 4850 lm / Lumen maintenance: L70 B50=50,000h
Driver
Diffuser
Beam width
Version
LED
K
CRI
lm
SDCM
Finishes
0
On/Off
D
Opal
77°
F670 1380mm
HW
2700
>90
5030
<3
12
L
Prismatic
85°
HQ
3000
>90
5465
<3
31
X
Ribbed
78°
WW
3000
>80
6285
<3
Q
Anti-glare louvre
60°
NN
4000
>80
6740
<3
V
Opal, U-Shape
104°
LED nominal lumen
