310542
3107574
3107575
310543
310523
310524
310978
310981
Architectural
NOTTURNO 500
IP66 - IK07
LUMINAIRE
WATTAGE [W]
CLASS
ENEC
CRI
KELVIN
OPTIC
BEAM ANGLE
LIGHTSOURCE LUMEN
OUTPUT [lm]
LUMINAIRE LUMEN
OUTPUT [lm]
COLOUR /
FINISH
LENGTH [mm]
PART NUMBER
UKCA
Power LED
20
III
-
80 4000
S/I
-
2016
1623
F
504
304899
ü
20
III
-
80 4000
S/M
-
2016
1609
F
504
304900
ü
20
III
-
80 4000
ELL
13°x36°
2016
1606
F
504
304901
ü
20
III
-
80 3000
S/I
-
2016
1623
F
504
304896
ü
20
III
-
80 3000
S/M
-
2016
1609
F
504
304897
ü
20
III
-
80 3000
ELL
13°x36°
2016
1606
F
504
304898
ü
Power LED DALI
20
III
-
80 4000
S/I
12°
2016
1623
F
504
3107538
ü
20
III
-
80 4000
S/M
30°
2016
1609
F
504
3107539
ü
20
III
-
80 4000
ELL
13°x36°
2016
1606
F
504
3107540
ü
20
III
-
80 3000
S/I
12°
2016
1623
F
504
3107534
ü
20
III
-
80 3000
S/M
30°
2016
1609
F
504
3107535
ü
20
III
-
80 3000
ELL
13°x36°
2016
1606
F
504
3107536
ü
NOTTURNO 1000
IP66 - IK07
LUMINAIRE
WATTAGE [W]
CLASS
ENEC
CRI
KELVIN
OPTIC
BEAM ANGLE
LIGHTSOURCE LUMEN
OUTPUT [lm]
LUMINAIRE LUMEN
OUTPUT [lm]
COLOUR /
FINISH
LENGTH [mm]
PART NUMBER
UKCA
Power LED
38
III
-
80 4000
S/I
-
4032
3122
F
972
304911
ü
38
III
-
80 4000
S/M
-
4032
3095
F
972
304912
ü
38
III
-
80 4000
ELL
13°x36°
4032
3088
F
972
304913
ü
38
III
-
80 3000
S/I
-
4032
3122
F
972
304908
ü
38
III
-
80 3000
S/M
-
4032
3095
F
972
304909
ü
38
III
-
80 3000
ELL
13°x36°
4032
3088
F
972
304910
ü
NOTTURNO 1500
IP66 - IK07
LUMINAIRE
WATTAGE [W]
CLASS
ENEC
CRI
KELVIN
OPTIC
BEAM ANGLE
LIGHTSOURCE LUMEN
OUTPUT [lm]
LUMINAIRE LUMEN
OUTPUT [lm]
COLOUR /
FINISH
LENGTH [mm]
PART NUMBER
UKCA
Power LED
54
III
-
80 4000
S/I
-
6064
4621
F
1440
304923
ü
54
III
-
80 4000
S/M
-
6064
4581
F
1440
304924
ü
54
III
-
80 4000
ELL
13°x36°
6064
4571
F
1440
304925
ü
54
III
-
80 3000
S/I
-
6064
4621
F
1440
304920
ü
54
III
-
80 3000
S/M
-
6064
4581
F
1440
304921
ü
54
III
-
80 3000
ELL
13°x36°
6064
4571
F
1440
304922
ü
Control gear
Mandatory accessories
DESCRIPTION
COLOR
PART NUMBER
UKCA
DESCRIPTION
COLOR
PART NUMBER
UKCA
NOTTURNO
Power Supply Unit L500
310542
ü
Power Supply Unit L1000/1500
310543
ü
NOTTURNO - DALI
Power Supply Unit DALI IN L500
3107574
ü
Boîtier d’alimentation DALI IN / OUT L500
3107575
ü
NOTTURNO
Bracket NOTTURNO (nr. 2)
F
310523
ü
Bracket (nr. 2)
B
310524
ü
NOTTURNO Telescopic bracket (nr. 2)
F
310978
ü
NOTTURNO ground support bracket (nr. 2)
F
310981
ü
469
