Linear surface mount (STRIP SQUARE+) and linear in-ground (STRIP SQUARE+ INGROUND) series.
Fixtures consist of:
Construction
- Extruded anodised aluminium housing
- Die-cast aluminium end caps, painted
- Aluminium gear tray for high heat dissipation of components
- Anti-ageing silicone gasket
- Tempered glass diffuser, screen-printed inside
- Stainless steel locking screws
Electrical
- Built-in driver
- Available with ON-OFF driver and dimmable DALI
- TW - TUNABLE WHITE(2700 ÷ 6500 K) version DALI DT8
Installation
- Adjustable wall mounting bracket with joint for directing the luminaire
- External electrical connection with IP-rated QUICK connector, complete with cable
- Recessed box to be ordered separately
- Each recessed box is delivered with a protective cover to avoid possible deformations during the
installation in concrete and spirit level to ease the levelling during installation
- For outdoor applications, provide drainage gravel for at least 300 mm additional to the appliance
or a suitable drainage system
- DMX signal generator for RGBW versions to be ordered separately
Listings
- CE
- EAC
- RCM
- Compliant to EN 60598-2-13 A1 / A2 / A3 / A4 / A5 installation areas
- Made in Italy
Warranty
- 5-year limited warranty. Complete warranty terms located at www.performanceinlighting.com
STRIP SQUARE+
design Roberto Fiorato
