LED-Driver
Emergency Kit Driver
L
N
L
N
P.E
ON/OFF
+
-
Led Lamp
+
-
Lent
L
N
Lsal
Control +
Bateria +
Bateria -
Control +
Led -
Led +
Pulsador
Test
LED
indicador
EMERGENCY KIT
LAMPS & COMPENENTS
h
W
Driver-V
Batery
Flux
Kit Emergencia
1
2.4
10-54V
1.6 Ah
70-100%
3
2.4
10-54V
4.2 Ah
70-100%
CBAL
CBAL
A
A
SR
SR
D
D
B
B
30
30
U
V
2
2
1H
3H
REFERENCES
WIRING DIAGRAM
KIT EMERGENCY FOR GU-10
LAMPS & COMPENENTS
h
W
Lamp
Batery
Flux
Kit Emergencia
1
3 - 8.5
GU 10
1.6 Ah
80-100%
3
3 - 8.5
GU 10
4 Ah
80-100%
LED Driver para luz de emergencia mantenida para pruebas
manuales. Kit con LED Driver de luz de emergencia, batería para
funcionamiento de 1 o 3 horas y LED de estado
Non-maintained emergency LED Driver for manual testing.
Kit with emergency lighting LED Driver, battery for 1 or 3 h
duration and indication LED
Kit de emrgencia 230Vsx para lampara led GU10, inluye Driver de
luz de emergencia, batería para funcionamiento de 1 o 3 horas y
LED de estado
Emergency light KIT for 230 Vdc LED lamps with GU 10 cap.
Kit with emergency lighting LED Driver, battery for 1 or 3 h
duration and indication LED
