OBJECT CARPET
Artikelname
Herstellungsart ISO 2414
Warenbreite ISO 3018
Oberseitengestaltung ISO 2424
Material der Nutzschicht ISO 2424
Rückenausrüstung ISO 2424
Flächengewicht ISO 8543
Gesamtdicke ISO 1765
Poleinsatzgewicht Herstellerangabe
Strapazierwert EN 1307
Komfortwert EN 1307
Trittschallminderung EN ISO 10140-1
Schallabsorptionsgrad EN ISO 11654
Brandverhalten EN 13 501
Velours
Getuftet
ca. 400 cm
ca. 50 x 50 cm
variabel bis 400 cm
Velours
100 % PA 6.6
Welltex® Circular Akustik
ca. 2200 g/m²
ca. 2200 g/m²
ca. 9,7 mm
ca. 1000 g/m²
Gewerblich stark (33)
LC3
+30 dB
0,3 aw
Bfl-s1
TECHNISCHE DATEN
TECHNICAL DATA
Glanz Velours
Getuftet
ca. 400 cm
ca. 50 x 50 cm
variabel bis 400 cm
Velours
100 % radifloor® piuma PA66
Welltex® Circular Akustik
ca. 2300 g/m²
ca. 2300 g/m²
ca. 10,5 mm
ca. 1200 g/m²
Gewerblich normal (32)
LC4
+32 dB
0,3 aw
Bfl-s1
Strukturschlinge
Getuftet
ca. 400 cm
ca. 50 x 50 cm
variabel bis 400 cm
Schlinge
100 % Econyl® by Aquafil
Welltex® Circular Akustik
ca. 1900 g/m²
ca. 1900 g/m²
ca. 8 mm
ca. 800 g/m²
Gewerblich stark (33)
LC3
+30 dB
0,3 aw
Bfl-s1
S
G
V
Name of article
Method of production ISO 2414
Width ISO 3018
Surface structure ISO 2424
Pile material ISO 2424
Secondary backing ISO 2424
Overall weight ISO 8543
Overall thickness ISO 1765
Pile service weight
Wearability EN 1307
Comfort class EN 1307
Sound absorption EN ISO 10140-1
Acoustical absorption EN ISO 11654
Flammability EN 13 501
Velours
Tuftet
approx. 400 cm
approx. 50 x 50 cm
variable until 400 cm
Cut
100% PA 6.6
Welltex® Circular Acoustic
approx. 2200 g/m²
approx. 2200 g/m²
approx. 9,7 mm
approx. 1000 g/m²
commercial use heavy (33)
LC3
+30 dB
0,3 aw
Bfl-s1
Glossy Velours
Tuftet
approx. 400 cm
approx. 50 x 50 cm
variable until 400 cm
Cut
100% radifloor® piuma PA66
Welltex® Circular Acoustic
approx. 2300 g/m²
approx. 2300 g/m²
approx. 10,5 mm
approx. 1200 g/m²
commercial use general (32)
LC4
+32 dB
0,3 aw
Bfl-s1
Structured Loop
Tuftet
approx. 400 cm
approx. 50 x 50 cm
variable until 400 cm
Loop
100% Econyl® by Aquafil
Welltex® Circular Acoustic
approx. 1900 g/m²
approx. 1900 g/m²
approx. 8 mm
approx. 800 g/m²
commercial use heavy (33)
LC3
+30 dB
0,3 aw
Bfl-s1
S
G
V
