MASIERO
116
117
NAPPE XL1
Ø
H
STANDARD INTEGRATED LED LIGHTING
UP
DOWN
ON REQUEST
UP
DOWN
DIMMABLE
NAPPE XM1
Ø
H
STANDARD INTEGRATED LED LIGHTING
UP
DOWN
ON REQUEST
UP
DOWN
DIMMABLE
NAPPE APP N2
W
15 cm / 5.90”
D
18 cm / 7.10”
H
42 cm / 16.50”
STANDARD INTEGRATED LED LIGHTING
5,4 W CRI>90
3000 K - 688 NOMINAL LM
ON REQUEST
5,4 W CRI>90
2700 K - 653 NOMINAL LM
DIMMABLE
NO
H
D
W
NAPPE APP N4
W
7,5 cm / 3.00”
D
14 cm / 5.50”
H
40 cm / 15.70”
STANDARD INTEGRATED LED LIGHTING
5,4 W CRI>90
3000 K - 688 NOMINAL LM
ON REQUEST
5,4 W CRI>90
2700 K - 653 NOMINAL LM
DIMMABLE
NO
H
D
W
H
Ø
NAPPE STL XM1
Ø
30 cm / 11.80”
H
165 cm / 65.00”
STANDARD INTEGRATED LED LIGHTING
UP
9 W CRI>90
3000 K - 1520NOMINAL LM
DOWN
4 W CRI>90
3000 K - 390 NOMINAL LM
ON REQUEST
UP
9 W CRI>90
2700 K - 1300 NOMINAL LM
DOWN
4 W CRI>90
2700 K - 335 NOMINAL LM
DIMMABLE
OWN BUTTON
386627_Masiero_Catalogo-Dimore2025_MONDO201224.indd 116
386627_Masiero_Catalogo-Dimore2025_MONDO201224.indd 116
13/01/25 12:17
13/01/25 12:17
117
Nappe
NAPPE XL1
Ø
30 cm / 11.80”
H
125 cm / 49.20”
STANDARD INTEGRATED LED LIGHTING
UP
6,6 W CRI>90
3000 K - 1150 NOMINAL LM
DOWN
9,2 W CRI>90
3000 K - 1450 NOMINAL LM
ON REQUEST
UP
6,6 W CRI>90
2700 K - 1092 NOMINAL LM
DOWN
9,2 W CRI>90
2700 K - 1370 NOMINAL LM
DIMMABLE
1-10V + DALI + PUSH
NAPPE XL2
Ø
35 cm / 13.80”
H
135 cm / 53.10”
STANDARD INTEGRATED LED LIGHTING
UP
6,6 W CRI>90
3000 K - 1150 NOMINAL LM
DOWN
9,2 W CRI>90
3000 K - 1450 NOMINAL LM
ON REQUEST
UP
6,6 W CRI>90
2700 K - 1092 NOMINAL LM
DOWN
9,2 W CRI>90
2700 K - 1370 NOMINAL LM
DIMMABLE
1-10V + DALI + PUSH
NAPPE XL3
Ø
30 cm / 11.80”
H
110 cm / 43.30”
STANDARD INTEGRATED LED LIGHTING
12,2 W CRI>90
3000 K - 2000 NOMINAL LM
ON REQUEST
12,2 W CRI>90
2700 K - 1900 NOMINAL LM
DIMMABLE
1-10V + DALI + PUSH
H
Ø
H
Ø
H
Ø
NAPPE XM1
Ø
20 cm / 7.90”
H
80 cm / 31.50”
STANDARD INTEGRATED LED LIGHTING
UP
9 W CRI>90
3000 K - 1520 NOMINAL LM
DOWN
4 W CRI>90
3000 K - 390 NOMINAL LM
ON REQUEST
UP
9 W CRI>90
2700 K - 1300 NOMINAL LM
DOWN
4 W CRI>90
2700 K - 335 NOMINAL LM
DIMMABLE
1-10V + PUSH
NAPPE XM2
Ø
24 cm / 9.45”
H
88 cm / 34.60”
STANDARD INTEGRATED LED LIGHTING
UP
9 W CRI>90
3000 K - 1520 NOMINAL LM
DOWN
4 W CRI>90
3000 K - 390 NOMINAL LM
ON REQUEST
UP
9 W CRI>90
2700 K - 1300 NOMINAL LM
DOWN
4 W CRI>90
2700 K - 335 NOMINAL LM
DIMMABLE
1-10V + PUSH
NAPPE XM3
Ø
20 cm / 7.90”
H
70 cm / 27.60”
STANDARD INTEGRATED LED LIGHTING
9 W CRI>90
3000 K - 1520 NOMINAL LM
ON REQUEST
9 W CRI>90
2700 K - 1300 NOMINAL LM
DIMMABLE
1-10V + PUSH
H
Ø
H
Ø
H
Ø
