C.V.
IP40
Node System_L |
Ø 34
L
Finishes
Cct
WH
White
M 2700
N
4000
BB
Black
W 3000
Node System_L |
L
22
10
Rubber_O | topLED | 48 V DC | 12 W/m
62.5
L 300
Ø 30
L
C.V.
>50
R9
IP65
Rubber_O |
Ø 34
80
55
Ø 34
IP20
Rubber_O |
Ø 34
284
55
Ø 34
IP20
60%
30%
60%
90%
60%
50%
WH
83309
L 629 mm
max 2 x spotlights or suspension spotlights
BB
83310
L 629 mm
max 2 x spotlights or suspension spotlights
WH
83311
L 1188 mm
max 4 x spotlights or suspension spotlights
BB
83312
L 1188 mm
max 4 x spotlights or suspension spotlights
WH
83313
L 1748 mm
max 6 x spotlights or suspension spotlights
BB
83314
L 1748 mm
max 6 x spotlights or suspension spotlights
WH
83316
L 1119 mm
BB
83317
L 1119 mm
WH
83318
L 1679 mm
BB
83319
L 1679 mm
Electronics: EK (pag 59) | Accessories (pag 58/59)
Cct lm S/m - lm D/m
Opt L
CRI 90
C0020
M
1538 - 1150
DI
02517 (2,5 m - 30 W)
W
1654 - 1256
05017 (5 m - 60 W)
N
1770 - 1284
10017 (10 m - 120 W)
WH
83297
BB
83298
WH
83305
BB
83306
I
L
H
H
H
48V DC | Electrified track module
Track cover
DALI2 connector
Connector
LIGHT MANAGEMENT
Dimming across the entire line
2% ---> 100%
(On/Off, Push Dim, 0/1-10V)
Dimming on a single light module
5% ---> 100%
(DALI2)
Accessory for electrical connection (On-Off)
+ Node System mechanical connection for Rubber_O modules.
Accessory for electrical connection (DALI2)
+ Node System mechanical connection for Rubber_O modules.
The Rubber_O module can be only be used in the wall/ceiling installations (it cannot be
installed on pendant configurations). Use the following connection accessories to join
Rubber_O to the system: 83297,83298 (On-Off) or 83305,83306 (DALI2).
Linear systems
51
