30
29
kreon down in-line 80
↑ back to kreon down in-line
catalogue 4
kreon.com/down-in-line
■ Required accessories
Double plasterkit
KR727114
Double plasterkit, front mounting, no shadowgap 1 LxW 102x177
Louvres
KR717116 x 2
Louvre, white
KR717112 x 2
Louvre, black
KR717113 x 2
Louvre, red satin copper
REMARKS
➊ IP44 connection in plenum
required.
➋ only one optional lens or
louvre possible
➌ use only in combination with
spot optic
See page 690 for more
information about different
installation kits.
Thickness boardmaterial:
9-26mm
■ Optional accessories
Lenses (only for directional) 2
KR704100 x 2
Sculpture lens ➌
KR704200 x 2
Diffusing lens
KR772342 x 2
Anti-glare louvre ➌
Driver 350mA
KR747064
LED driver, 350mA, ON/OFF, 0,7-19W
KR747162
LED driver, 350mA, 1-10V, 6-18W
KR747266
LED driver, 350mA, DALI, 3,5-17W
KR772219
LED driver, 350mA, Casambi, 3,5-18,5W
Driver 700mA
KR772034
LED driver, 700mA, ON/OFF, 20W,
KR772232
LED driver, 700mA, 1-10V, 20W
KR772236
LED driver, 700mA, DALI, 18W
KR772430
LED driver, 700mA, phase dim, 25W
KR772931
LED driver, 700mA, phase dim, 14W
KR772239
LED driver, 700mA, Casambi, 36W
