22
21
kreon down 80
102
96
116
360°/30°
102
96
94
360°/30°
down 80 directional LED PAR16
down 80 directional LED MR16
102
96
360°/30°
down 80 directional with LED engine
↑ back to kreon down
catalogue 4
kreon.com/down
Voltage
Wattage
➀
LED MR16
12V
15W
➁
LED PAR16
230V
15W
Colour
KR-code
Light sources
Required accessories
Optional accessories
down 80 directional LED MR16
1 LxW 91x91 H 110 4
Filter holder: incl., lamp: excl., glare snoot: incl.
○
KR947801
➀
■
●
KR947802
➀
■
down 80 directional LED PAR16
1 LxW 91x91 H 125 6
Filter holder: incl., lamp: excl., glare snoot: incl.
○
KR947841
➁
■
●
KR947842
➁
■
down 80 directional with LED engine 50
1 LxW 91x91 H 120 4
Glare snoot: incl.
○
KR947201
■
■
●
KR947202
■
■
REMARKS
➊ Suitable for indoor
applications.
Connecting multiple modules in
parallel on one LED driver is not
permitted. Connecting multiple
modules in series on one LED
driver is not recommended.
Available in 4000K on request.
Thickness boardmaterial:
9-26mm
Gear excluded.
IP40
■ Required accessories
LED engine ➊
KR737300-9027-SP
LED engine 50, 2700K, CRI90+, 15°, 12,2W, 350mA (981lm)
KR737300-9027-FL
LED engine 50, 2700K, CRI90+, 24°, 12,6W, 350mA (1000lm)
KR737300-9027-WFL
LED engine 50, 2700K, CRI90+, 40°, 12,6W, 350mA (1000lm)
KR737300-9030-SP
LED engine 50, 3000K, CRI90+, 15°, 12,2W, 350mA (1032lm)
KR737300-9030-FL
LED engine 50, 3000K, CRI90+, 24°, 12,6W, 350mA (1050lm)
KR737300-9030-WFL
LED engine 50, 3000K, CRI90+, 40°, 12,6W, 350mA (1100lm)
■ Optional accessories
Plasterkit concrete
KR747702
Plasterkit for concrete installation
Driver for LED engine
KR747064
LED driver, 350mA, ON/OFF, 0,7-19W
KR772511
LED driver, 350mA, phase dim, 3,5-16,8W
KR752743
LED driver, 350mA, phase dim, 0,7-17W
KR747162
LED driver, 350mA, 1-10V, 6-18W
KR747266
LED driver, 350mA, DALI, 3,5-17W
KR772219
LED driver, 350mA, Casambi, 3,5-18,5W
