kreon prologe 40
kreon.com
45
85
157,5
100
50
45
85
157,5
100
50
prologe 40 double deep louvre
prologe 40 double
REMARKS
➊ Louvre for DL/WDL is always
black
➋ Driver must be placed on
remote
IP40
■ Optional accessories
Driver ➋
KR772024
LED driver, 500mA, ON/OFF, 20W
KR772220
LED driver, 500mA, 1-10V, 20W
KR772542
LED driver, 500mA, phase dim, 18W
KR752843
LED driver, 500mA, phase dim, 24W
KR772126
LED driver, 500mA, DALI, 18W
KR772123
LED driver, 500mA, DALI, 27W
Installation cover
KR767241
Installation cover prologe 40 double, white
KR767242
Installation cover prologe 40 double, black
Colour
KR-code
Light sources
9027
2700K, CRI90
9030
3000K, CRI90
SP
Spot (20°)
FL
Flood (30°)
WFL
Wide flood (38°)
DL
Dark light (40°) ➊
WDL
Wide dark light (76°) ➊
EX
Driver excluded
SW
Switchable ON/OFF
PD
Phase dimming
Optional accessories
prologe 40 double
○
KR967341
1
●
●
●
●
●
●
●
●
●
●
■
●
KR967342
1
●
●
●
●
●
●
●
●
●
●
■
prologe 40 double, deep louvre
Driver: excl.
○
KR967441
➁
●
●
●
●
●
●
■
●
KR967442
➁
●
●
●
●
●
●
■
Installation cover
prologe 40 double
CRI
CCT
Voltage
Wattage
Drive current
Fixture lumen
➀
LED
EX
FL
CRI90+
2700K/3000K
12W
500mA
912lm
DL CRI90+
2700K/3000K
12W
500mA
622lm
SW/PD FL
CRI90+
2700K/3000K
230V
12W
912lm
DL CRI90+
2700K/3000K
230V
12W
621lm
➁
LED
EX
FL
CRI90+
2700K/3000K
12W
500mA
747lm
kreon prologe 40 double
