kreon oran
58
71
Ø80
oran in-line craft sphere bulb
135
71
Ø80
oran in-line craft long ampoule
20
61
Ø120
Ø80
oran in-line stone
CRI
CCT
Wattage
Drive current
Fixture lumen ➋
➀
LED
CRI90+
2700K/3000K
6,7W
700mA
282lm
➁
LED
CRI90+
2700K/3000K
6,7W
700mA
68lm
kreon oran in-line
Plasterkit concrete
REMARKS
➊ Protect the alabaster
against direct sunlight and
temperatures above 50°C.
➋ Lumen output may vary due
to the use of natural products.
The stated dimensions are
only to be used as a reference.
Actual dimensions may vary.
Each unit is unique due to the
artisanal production technique.
Thickness boardmaterial:
9-26mm
Gear excluded.
4 IP40
■ Required accessories
Plasterkit
KR717104
Plasterkit, no shadowgap
KR717108
Plasterkit, with shadowgap
Plasterkit concrete
KR717102
Plasterkit for concrete installation, no shadowgap, small (200x200)
KR717107
Plasterkit for concrete installation, shadowgap, small (200x200)
Louvre
KR717106
Louvre, white
KR717122
Louvre, black
KR717105
Louvre, gun black
KR717103
Louvre, copper red satin
■ Optional accessories
Driver
KR772024
LED driver, 700mA, ON/OFF, 1-20W
KR772232
LED driver, 700mA, 1-10V, 1,4-20W
KR772236
LED driver, 700mA, DALI, 5,5-18W
KR772433
LED driver, 700mA, phase dim, 5-10W
Distance ring (for plasterkit concrete)
KR717307
Distance ring 2mm (set of 5 pcs.)
KR717308
Distance ring 3mm (set of 5 pcs.)
KR717309
Distance ring 5mm (set of 5 pcs.)
KR-code
Light sources
9027
2700K, CRI90+
9030
3000K, CRI90+
Required accessories
Optional accessories
oran in-line craft sphere bulb
1 Ø 102 H 100
KR991102
➀
●
●
■
■
oran in-line craft long ampoule
1 Ø 102 H 100
KR991105
➀
●
●
■
■
oran in-line stone ➊
1 Ø 102 H 100
KR991101
➁
●
●
■
■
Plasterkit
