kreon holon 60
catalogue 3
kreon.com/holon
■ Required accessories
Recessed mounting
TBD
Installation box
KR791211-LV
Low voltage connection box Ø65x52mm, white, for holon 60 pendant gear excl. ➋
KR791212-LV
Low voltage connection box Ø65x52mm, black, for holon 60 pendant gear excl. ➋
KR791211-HV
High voltage connection box Ø65x52mm, white, for holon 60 pendant gear incl. ➌
KR791212-HV
High voltage connection box Ø65x52mm, black, for holon 60 pendant gear incl. ➌
■ Optional accessories
Driver 300mA for SSP & SP
KR747464
LED Driver, 300mA, ON/OFF, 16W ➊
KR747562
LED Driver, 300mA, 1-10V, 15W ➊
KR747666
LED Driver, 300mA, DALI, 16W ➊
KR772209
LED Driver, 300mA, Casambi, 16W ➊
Driver 500mA for FL & WFL
KR772024
LED Driver, 500mA, ON/OFF, 20W ➊
KR772220
LED Driver, 500mA, 1-10V, Push-dim, 20W ➊
KR772223
LED Driver, 500mA, DALI, 20W ➊
KR772229
LED Driver, 500mA, Casambi, 27W ➊
installation
recessed
mounted
surface
mounted
connection box
REMARKS
➊ Plenum height needs to be
150mm to push driver trough
plasterkit.
➋ Box does not contain driver.
Install driver on remote.
➌ Suitable for 230V connection.
