For the latest product data please refer to the web page. For accessories and colour selection use the online product configurator.
intra-lighting.com/#lineLED
M A I N F E A T U R E S
Linear installations with
quick connection for RVP
Highly efficient
and uniform illumination
Easy installation
For all creative compositions with corner instal-
lations or other shapes, a line connector with
wire (5 cm) is available.
Brings out colour and creates contrast in the
ambient. With its compact size and various
mounting possibilities, it’s easy to integrate it
under shelves, showcases, but also wardrobes
or cascades.
Cascades
Flexible compositions
for RVP
RVW
CS/CT
Recessed for wood
Ceiling
Luminaire luminous flux/m
380-800 lm/m
380-800 lm/m
Optics
SOP
SOP
LED colour
927, 930, 935, 940, RGB
927, 930, 935, 940, RGB
Driver
Casambi, DALI, FO
Casambi, DALI, FO
Driver position
Remote
Remote
Colour
1
2
1
2
Dimensions
L (mm): 542 - 2542
L (mm): 517 - 2517
L
26
14
L
17
16
Single
Line
Single
Line
LineLED
Technical Overview
CT
CS
L
20
20
Light source: High-flux LED strip, CRI>90,
MacAdam≤2, 50000h L90 B10 at 35°C. Optic: Satin
opal polycarbonate diffuser (SOP). Body: Extruded
aluminium profile, powder coated. Control gear:
Constant voltage driver - order separately. Power
supply: 24V DC.
≥ 90 %
GR0
year
WARRANTY
* For Line versions the LED strip and profile must be ordered separately.
Lichtsystem: High-flux LED strip, CRI>90, MacA-
dam≤2, 50000h L90 B10 bei 35°C. Optisches System:
Opal satinierter Diffusor Polycarbonat (SOP). Leuch-
tenkörper: Profil aus extrudiertem Aluminium,
pulverbeschichtet. Elektrische Ausführung: Kons-
tantspannung Treiber - separat bestellen. Netzspan-
nung: 24V DC.
Fuente de luz: Tira de LEDes de alta intensidad,
CRI>90, MacAdam≤2, 50 000 h L90 B10 a 35°C.
Óptica: Difusor de policarbonato opal satinado (SOP).
Cuerpo: Perfil de aluminio extruido, recubierto con
pintura en polvo. Equipo: Driver de voltaje constante
- pedir por separado. Fuente de alimentación: 24V DC.
