6 – lilu
lilu – 7
lilu
W1
W1
W2
W2
W3
W1 + W2
W1 + W2
W2 +W3
W2 +W3
W1 + W2
W1 + W2
W1 + W2 + W3
W1 + W2 + W3
W1 + W2 + W3
W1 + W2 + W3
38,5
50,5
24,0
30,0
16,3
24,0
36,0
11,6
17,6
30,0
24,0
36,0
30,0
18,0
18,0
12,0
12,0
6,0
6,0
12,0
12,0
12,0
12,0
12,0
12,0
6,0
6,0
6,0
6,0
11,6
11,6
17,6
17,6
56,5
68,5
30,0
36,0
16,3
Planning and dimensions overview
Overhangs, movability of lilu
Planning and dimensions overview
possible shelf combinations of lilu
W2 in front of W1
- W2 can be wider than W1
- The overhang of W2 over W1 can be freely chosen
W3 in front of W2
- width W2 ≥ W3 (W2 must be at least as wide as W3 or wider)
- max. 1/4 of the W3 width is able to exceed W2
Subsequent movability of the shelves to the left or right (dimensions in cm)
Shelf width in cm
W2 movable in front of W1
and in front of wall
W3 movable in front of wall
W3 movable in front of W2 = max. lateral
overhang of W3 over W2
40
–
0
10.0
60
0
5.0
15.0
80
5.0
10.0
20.0
100
10.0
12.5
25.0
120
12.5
15.0
30.0
140
–
17.5
35.0
160
15.0
–
–
180
–
–
–
200
20.0
–
–
240
25.0
–
–
- max. lateral overhang is 1/4 of the width of W3
W3 may not be wider than W2
For special sizes, lateral overhang on request.
The flexible shelves can also be
easily rearranged at a later date.
