DART Ø 55 mm 24V
DART Ø 55 mm 24V OPAL
Code
Lamp
W
Real Lm
Optic
1654
OS - natural anodization
ON - black anodization
IN - stainless steel
27K - 2700K
3K - 3000K
4K - 4000K
LED
4
355
30°
Ottiche opzionali / Optional optics
10° (code + 10), 54° (code + 54)
Driver esterno non compreso / Remote driver to be ordered separately (page 52)
PWM dimmable (page 354)
Su richiesta / On request
Lunghezza cavo 7 m / 7 m cable length (code + MT7)
Code
Lamp
W
Real Lm
Optic
1656
OS - natural anodization
ON - black anodization
IN - stainless steel
27K - 2700K
3K - 3000K
4K - 4000K
LED
4
44
diffuse
Driver esterno non compreso / Remote driver to be ordered separately (page 52)
PWM dimmable (page 354)
Su richiesta / On request
Lunghezza cavo 7 m / 7 m cable length (code + MT7)
DART
Code
Description
1657
Cassaforma cilindrica Ø 55 mm in tecnopolimero / Cylindrical recessed box Ø 55 mm in technopolymer
1658
Cassaforma Ø 55 mm in tecnopolimero / Recessed box Ø 55 mm in technopolymer
code 1657
code 1658
Incasso a terra, a parete e soffitto / Ground, wall and ceiling recessed
CASSAFORME / RECESSED BOXES Ø 55 mm 24V
ø 55
ø 55
82
82
code 1658
DART
Accessori / Accessories
CLIP Ø 55 mm
ø 80.5
ø 50
ø 52
100
100
Code
Description
1650
Clip di fissaggio a soffitto/parete in cartongesso per fori Ø 52 mm / Plasterboard ceiling/wall fixing clip for Ø 52 mm holes
22
ø 56
ø 52
code 1657
34
35
catalogue 2025
