DART Ø 35 mm OPAL
CASSAFORME / RECESSED BOXES Ø 35 mm
DART Ø 35 mm
Code
Lamp
W
Real Lm
Optic
1633
OS - natural anodization
ON - black anodization
IN - stainless steel
27K - 2700K
3K - 3000K
4K - 4000K
LED
350mA
2
126
27°
1634
LED 24V
Ottiche opzionali / Optional optics
11° (code + 11), 42° (code + 42)
Driver esterno non compreso / Remote driver to be ordered separately (pages 52-53)
1634 PWM dimmable (page 354)
Su richiesta / On request
Lunghezza cavo 7 m / 7 m cable length (code + MT7)
Code
Lamp
W
Real Lm
Optic
1635
OS - natural anodization
ON - black anodization
IN - stainless steel
27K - 2700K
3K - 3000K
4K - 4000K
LED
350mA
2
13
diffuse
1636
LED 24V
Driver esterno non compreso / Remote driver to be ordered separately (pages 52-53)
1636 PWM dimmable (page 354)
Su richiesta / On request
Lunghezza cavo 7 m / 7 m cable length (code + MT7)
DART
Code
Description
1631
Cassaforma cilindrica Ø 35 mm in tecnopolimero / Cylindrical recessed box Ø 35 mm in technopolymer
1632
Cassaforma Ø 35 mm in tecnopolimero / Recessed box Ø 35 mm in technopolymer
code 1631
code 1632
code 1631
code 1632
Incasso a terra, a parete e soffitto / Ground, wall and ceiling recessed
DART
Accessori / Accessories
ø 35
ø 35
81
81
ø 32
80.5
ø 32
100
100
CLIP Ø 35 mm
Code
Description
1630
Clip di fissaggio a soffitto/parete in cartongesso per fori Ø 32 mm / Plasterboard ceiling/wall fixing clip for Ø 32 mm holes
21
ø 36
ø 32
32
33
catalogue 2025
