code 1950
code 1957
code 1966
code 1966
code 1956
code 1965
code 1965
124
79
22
103
67
22
20
30
170
37
22
50
32
13
DRIVER DIMMERABILI DALI / DALI DIMMABLE DRIVERS
DRIVER DIMMERABILE PWM / PWM DIMMABLE DRIVER
PROTETTORI DI SOVRATENSIONI / SURGE PROTECTION DEVICES (SPD)
Code
IP
Description
1956
20
INPUT 220-240V o 110-127V AC o DC - OUTPUT 350 mA (17W) / 700 mA (32W)
1957
INPUT 220-240V o 110-127V AC o DC - OUTPUT 350 mA (39W) / 700 mA (60W)
1950
67
INPUT 220-240V AC o DC - OUTPUT 250 mA (12W) / 700 mA (23W)
Code
W
IP
Description
1953
40
67
INPUT 220-240V AC - OUTPUT 24V DC
Code
Description
1965
SPD type 2+3 Class I 10kV IP67
1966
SPD type 3 Class II 10kV
Da installare ad una distanza max 10 m per proteggere da disturbi di rete /
To be installed at max 10 m distance to protect against overvoltage
ACCESSORI
ACCESSORIES
ACCESSORI
ACCESSORIES
33
130
63
ø23
68
24
95
44
code 1944
code 1943
code 1944
code 1943
code 1941
code 1941
code 1942
code 1942
ø23
85
GIUNTI STAGNI / WATERPROOF CONNECTIONS
Code
Description
1941
Connessione singola 3x2,5 mm2 IP68 / Single connector 3x2,5 mm2 IP 68
1942
Connessione entra-esci 3x2,5 mm2 IP68 / Through wiring connector 3x2,5 mm2 IP 68
1943
Connessione singola presa-spina 3x2,5 mm2 IP68 / Plug/socket connector 3x2,5 mm2 IP 68
1944
Connessione fino a 4 uscite 3x2,5 mm2 IP68 (basato su gel siliconico bicomponente) / Up to 4 outputs connector 3x2,5 mm2 IP 68,
based on two-component silicone gel
103
26
47
150
35
53
354
catalogue 2025
355
