*Energy efficiency class: at a range of energy efficiency classes from A+++ to D.
Oven 200 series
BO P 210/BO P 211
Controls at the top
Right-hinged
BO P 210 102
Full glass door in Gaggenau
Anthracite.
Width 60 cm.
BO P 210 112
Full glass door in Gaggenau Metallic.
Width 60 cm.
BO P 210 132
Full glass door in Gaggenau Silver.
Width 60 cm.
Left-hinged
BO P 211 102
Full glass door in Gaggenau
Anthracite.
Width 60 cm.
BO P 211 112
Full glass door in Gaggenau Metallic.
Width 60 cm.
BO P 211 132
Full glass door in Gaggenau Silver.
Width 60 cm.
Included in the price
1 baking tray, enamelled
pyrolysis-safe.
1 wire rack.
1 enamelled tray.
Special accessories
B A 036 102
Wire rack, chromium-plated.
Without opening, with feet.
B A 046 117
Glass tray.
24 mm deep.
B A 056 115
Heating element for baking stone and
Gastronorm roaster.
B A 056 130
Baking stone.
Incl. baking stone support and pizza
paddle (heating element must be
ordered separately).
Not in combination with pull-out
system.
B A 216 102
Quadruple telescopic pull-out rack.
For oven BOP 210/BOP 211.
B A 226 102
Grill tray, enamelled.
37 mm deep.
B A 226 112
Baking tray, enamelled.
24 mm deep.
B S 020 002
Pizza paddle, set of 2.
A
Highlights
— Flush installation.
— 9 heating methods, with baking
stone function.
— TFT touch display.
— Panel-free appliance with surface
control module.
— Electronic temperature control
from 50 °C to 300 °C.
— Net volume 76 litres.
Heating methods
Hot air.
Eco hot air.
Top + bottom heat.
Top heat.
Bottom heat.
Hot air + bottom heat.
Full surface grill + circulated air.
Full surface grill.
Baking stone function.
Handling
Rotary knob and TFT touch display
operation.
Clear text display.
Option to save individual recipes.
Information key with use indicators.
Side-opening door opens up to
110° angle.
Features
Baking stone socket.
Actual temperature display.
Rapid heating.
Timer functions: cooking time, cooking
time end, timer, stopwatch, long-term
timer (certified by Star-K).
60 W halogen light on the top.
Chromium-plated wire racks on the
side with 4 rack levels.
Selected digital services
(Home Connect)
Remote control and monitoring.
Recipes.
Please read additional information on
Home Connect on page 409.
Safety
Thermally insulated door with triple
glazing.
Child lock.
Safety shut-off.
Cooled housing with temperature
protection.
Cleaning
Gaggenau enamel.
Heated catalyser to clean the oven
air.
Planning notes
Door hinge not reversible.
The door panel surface of the
appliance extends 21 mm from the
furniture cavity.
The outer edge of the door handle
extends 72 mm from the furniture
cavity.
Necessary lateral gap between
appliance door and furniture panel of
min. 5 mm.
Consider the overhang, incl. the door
handle, when planning to open
drawers next to the appliance.
When planning a corner solution, pay
attention to the side-opening door
and the minimum required distance
to the wall.
For installation underneath cooktops:
Distance between the underside of
the cooktop and the top edge of the
oven cavity: min. 15 mm.
The planning notes for the cooktops
(particularly regarding ventilation,
gas/electric connection) must be
taken into account.
To achieve the 550 mm installation
depth, the connection cable needs to
follow the slanted edge on the corner
of the housing.
The mains socket needs to be planned
outside the built-in niche.
The LAN port can be found at the
back on the upper right side.
Please read the installation details
regarding oven combination on
page 14–15.
Connection
Energy efficiency class A at a range
of energy efficiency classes from
A+++ to D.
Total connected load 3.7 kW.
Plan a connection cable.
Plan a LAN cable.
Ovens 200 series
58
