Dishwasher 200 series
D F 210
D F 210 100
Fully integrated.
Height 81.5 cm.
Included in the price
1 baking tray spray head.
Installation accessories
D A 020 011
Stainless steel trim kit for 81.5 cm high
dishwashers.
G H 045 010
Handle bar with 2 mounts, stainless
steel, length 45 cm, height 49 mm,
drilling distance 427 mm.
G Z 010 011
Extension for water inlet and outlet
(2 m long).
Special accessories
D A 041 061
Cutlery drawer.
3rd loading level above the upper
basket.
For large pieces of cutlery, cooking
utensils and espresso cups.
14 place setting capacity with all
3 levels.
D A 042 030
Silvercare cartridge for all
dishwashers.
D A 043 000
Holder for long-stemmed glasses.
Offers safe positioning for up to four
long-stemmed glasses during the
dishwashing process and ensures an
optimal cleaning result.
For positioning in the lower basket.
Highlights
— 6 programmes with aqua sensor
and 3 options, such as Power for
cleaning and drying dishes from
57 minutes and Intensive for
particularly thorough cleaning in
the lower basket.
— Flexible basket system.
— Bright interior lighting.
— Very quiet: 44 dB.
Handling
TFT display indicating remaining or
end time, refill for salt and rinsing
agent, inflow of water.
Touch key operation.
Flexible cycle time reduction, even
during an active cycle.
Personalisation function for saving
individual combinations of
programmes.
Information key with use indications.
Time delay up to 24 hours.
Visual and acoustic end of
programme indicator.
Info-Light.
Technical features
Bright interior lighting.
Glass protection.
Aqua sensor.
Load sensor.
Detergent recognition.
Regeneration electronics.
Heat exchanger.
Continuous flow heater.
Triple filter system.
Soft lock.
Aqua stop.
Selected digital services
(Home Connect)
Downloadable programmes.*
Programme assistant.
Temporary noise reduction.
Please read additional information on
Home Connect on page 409.
Programmes
6 programmes:
Auto 35 °C – 45 °C.
Auto 45 °C – 65 °C.
Auto 65 °C – 75 °C.
Eco 50 °C.
Quick wash 45 °C (29 min.).
Personalisation function
(default setting: Pre-rinse).
3 options:
Intensive.
Power.
Extra Dry.
Interior
Flexible basket system.
Upper basket:
Over extension.
Rackmatic with 3 levels, adjustable in
height up to 5 cm.
6 folding spines.
4 folding racks for optimal protection
of glass.
Lower basket:
8 folding spines.
2 folding racks for optimal protection
of glass.
Dividable glass support.
Cutlery basket.
Maximum dish sizes
(upper/lower basket)
for 81.5 cm high dishwashers:
27/25, 24.5/27.5 or 22/31 cm
respectively.
13 place setting capacity.
Maximum glass loading capacity
23 wine glasses.
Consumption data
Energy efficiency class D at a range of
energy efficiency classes from A to G.
From 9.5 l water.
From 0.836 kWh.
Noise level 44 dB (re 1 pW).
Planning notes
Height-adjustable feet.
Appliance plinth recess 100 mm
(see drawing).
Rear feet adjustable at front.
Door weight up to 8.5 kg.
Door panel dimension dependent on
plinth height of kitchen furniture.
Please read additional planning notes
on page 390–397.
Connection
Total connected load 2000-2400 W.
Connecting cable pluggable.
Water connection with 3/4" screw
joint.
Connection to hot or cold water
possible.
Dishwasher
388
