*Energy efficiency class: at a range of energy efficiency classes from A+++ to D.
Wall-mounted hood 400 series
A W 442
A W 442 120
Stainless steel.
Width 120 cm.
Air extraction / Air recirculation.
Motorless.
Chimney needs to be ordered
separately.
In combination with remote fan units
AR 400 143
AR 400 142
AR 401 142
Necessary Installation accessories
A D 442 012
Stainless steel chimney for air
extraction.
Length: 620 mm.
A D 442 022
Stainless steel chimney for air
extraction.
Length: 860 mm.
A D 442 112
Stainless steel chimney for air
recirculation.
Length: 620 mm.
A D 442 122
Stainless steel chimney for air
recirculation.
Length: 860 mm.
A A 442 810
Air recirculation module inclusive
2 activated charcoal filters with highly
efficient odour reduction.
For air recirculation.
Special accessories
(order as spare parts):
Part No. 11049036
2 activated charcoal filters with highly
efficient odour reduction. For air
recirculation module AA 442 810.
Installation accessories for air ducting
you will find at the pages 284–293.
A
Highlights
— Professional technology hood
combined with classic Gaggenau
design.
— Highly efficient extraction of
cooking vapours due to large
vapour collection area.
— Motorless, can be combined with
Gaggenau BLDC remote fan units.
— Angled baffle filter with high
grease absorption.
— Function for automatic,
sensor-controlled power
adjustment depending on the
build-up of cooking vapours.
— Dimmable, neutral white surface
LED light for ideal illumination of
the cooktop.
— Air extraction or air recirculation
system.
— Air recirculation module with
activated charcoal filter: quiet and
highly efficient air recirculation
solution with odour reduction as in
air extraction mode and long
replacement intervals.
Output
Power levels depend on the remote
fan unit.
Refer to the "Technical specifications"
of the hood for the matching remote
fan units for air recirculation or air
extraction mode.
Features
3 electronically controlled power
levels and 1 intensive mode.
Automatic function with sensor-
controlled run-on function.
Grease filter saturation indicator.
Baffle filter, dishwasher-safe.
Neutral white surface LED light (3500 K),
continuously dimmable.
Lamp output 4 x 10 W.
Illuminance 1010 lx.
Easy mounting system for simple
installation and alignment.
Consumption data
Consumption data is referred to a
configuration AW 442 120 with the
remote fan unit AR 400 143.
Energy efficiency class A at a
range of energy efficiency classes
from A+++ to D.
Energy consumption 48.1 kWh/year.
Ventilation efficiency class A.
Ilumination efficiency class B.
Grease filter efficiency class B
Sound level min. 47 dB /
max. 64 dB normal mode.
Planning notes
The equivalent ducting length to
ensure good performance is Lmax 26 m.
The two-part chimney must be
ordered as an installation accessory.
Connection to the respective
appliances via network cable.
Two chimney lengths are available
depending on the height of the room.
The AR 400 143 remote fan unit is
ideal for space-saving installation for
assembly in the AW 442.
Clearance above gas appliances min.
70 cm.
Clearance above electric appliances
min. 60 cm.
Air recirculation module with
2 activated charcoal filters is installed
in the inner chimney. Special air
recirculation chimneys are available
for this.
When installing a ventilation hood
with air extraction mode and a
chimneyvented fireplace, the power
supply line of the ventilation
appliance needs a suitable safety
switch.
Connection
Total connected load 40 W
Connecting cable 1.8 m, pluggable.
