243
242
Omar Carraglia / 2006
MISS
MISS
Omar Carraglia / 2006
Compulsory accessories / Accessori obbligatori
Drivers / Alimentatori
Driver / Alimentatore
Not included
220-240V(100-127V)
350mA/17W(15W)/IP20/DALI
MISS 2
1Z0241180.350
Driver / Alimentatore
Not included
220-240V(100-127V)
350mA/18W(15W)/IP20/PUSH - 1-10V
MISS 2
1Z0240870.350
Driver / Alimentatore
Not included
220-240V
350mA/17W/IP20/TRIAC/IGBT
MISS 2
1Z0240850.350
Optional accessories / Accessori opzionali
Suspension kits / Kit di sospensione
Decentralization kit / Kit decentratore
Not included
MISS 1
1A0360000.00.00
Kit ceiling rose and decentralizer / Kit rosone e decentratore
Not included
Matt White
White cable 3 m included
MISS 1
1A0770300.00.00
Matt Black
Black cable 3 m included
MISS 1
1A0770400.00.00
Recessed suspension kit for 12,5 mm plasterboard / Kit di sospensione da incasso per cartongesso 12,5 mm
Not included
Matt White
For elettrical cables - 1 Piece
Plasterboard cut-out Ø 44 mm
Minimum space for mounting 70 mm
MISS 2
1X0000300.06.00
Matt Black
For elettrical cables - 1 Piece
Plasterboard cut-out Ø 44 mm
Minimum space for mounting 70 mm
MISS 2
1X0000400.06.00
Ceiling suspension kit / Kit di sospensione da soffitto
Not included
Matt White
For elettrical cables - 1 Piece
MISS 2
1X0010300.06.00
Matt Black
For elettrical cables - 1 Piece
MISS 2
1X0010400.06.00
Wall adapter plate / Piastra di adattamento da parete
Not included
Matt White
For mounting on brick masonry walls
MISS 2
1X0050300.01.00
MISS 2
Remote driver version
4W
Max 350mA DC
2700K - 290lm / 3000K - 310lm
CRI >90
Driver not included
Matt White - 2700K
1A2960300.27.20
Matt White - 3000K
1A2960300.30.20
Matt Black - 2700K
1A2960400.27.20
Matt Black - 3000K
1A2960400.30.20
Brushed Brass - 2700K
1A2960800.27.20
Brushed Brass - 3000K
1A2960800.30.20
Total Black - 2700K
1A2962600.27.20
Total Black - 3000K
1A2962600.30.20
Polished Black Chrome - 2700K
1A2962800.27.20
Polished Black Chrome - 3000K
1A2962800.30.20
MISS ENDLESS
Endless version only
6,3W - 0,16A
48V DC
2700K - 290lm / 3000K - 310lm
CRI >90
Driver not included
See page ENDLESS
Matt White - 2700K
1A2960300.27.40
Matt White - 3000K
1A2960300.30.40
Matt Black - 2700K
1A2960400.27.40
Matt Black - 3000K
1A2960400.30.40
Brushed Brass - 2700K
1A2960800.27.40
Brushed Brass - 3000K
1A2960800.30.40
Total Black - 2700K
1A2962600.27.40
Total Black - 3000K
1A2962600.30.40
Polished Black Chrome - 2700K
1A2962800.27.40
Polished Black Chrome - 3000K
1A2962800.30.40
