Michele Groppi / 2023
MAGIA
MAGIA
Michele Groppi / 2023
Compulsory accessories / Accessori obbligatori
Drivers / Alimentatori
Ceiling driver / Driver da soffitto
Not included
Matt White
Input 220-240V - 50/60Hz
Output 24V - 21W - IP20
DALI - PUSH - 1-10V - TRIAC
Max 1 module
1A4780300.00.05
Ceiling driver / Driver da soffitto
Not included
Matt White
Input 110-240V - 50/60Hz
Output 24V - 60W - IP20
DALI - PUSH - 1-10V - TRIAC
Max 3 modules
1A4740300.00.05
Driver / Alimentatore
Not included
100-240V
24V/50W/IP20/ON/OFF
Max 1 module
1Z1120490
Driver / Alimentatore
Not included
100-240V
24V/80W/IP20/ON/OFF
Max 3 modules
1Z1120440
Driver / Alimentatore
Not included
100-240V
24V/150W/IP67/1-10V
Max 6 modules
1Z1120500
Controller
Not included
DALI - PUSH - 0/1-10V - TRIAC - IP20
1Z2170010
Optional accessories / Accessori opzionali
Suspension kits / Kit di sospensione
Wall adapter plate / Piastra di adattamento da parete
Not included
Matt White
For mounting on brick masonry walls
1X0050300.01.00
Suspension / Direct-Indirect / Indoor
Material
Metal - PMMA
Finish
.19 Polished Gold
.28 Polished Black Chrome
Note
Modular suspension luminaire. Adjustable along the horizontal axis.
Transparent bar with refractive effect. LED module profile with matt black
finish. Details with polished gold or black chrome finish. Matt white rose.
Possibility for the luminaire to be powered by ENDLESS conductive tape
and by dedicated voltage/current (Max 48V DC - Max 150W - Max 4A). See
page: ENDLESS.
Apparecchio illuminante a sospensione componibile. Orientabile lungo
l’asse orizzontale. Barra trasparente con effetto rifrattivo. Profilo del modulo
LED con finitura nero opaco. Dettagli con finitura oro lucido o cromo nero.
Rosone bianco opaco. Alimentabile anche con il tape conduttivo ENDLESS e
tensione/corrente dedicata (Max 48V DC - Max 150W - Max 4A). Vedi pagina
ENDLESS.
MAGIA - MODULE
19W
24V DC
2700K - 1272lm / 3000K - 1312lm
CRI >90
Driver not included
Polished Gold - 2700K
1A4721900.27.20
Polished Gold - 3000K
1A4721900.30.20
Polished Black Chrome - 2700K
1A4722800.27.20
Polished Black Chrome - 3000K
1A4722800.30.20
Compulsory accessories / Accessori obbligatori
Installation kits / Kit d'installazione
Wire guide / Guidacavo
Not included
Matt Black
1 Piece
1A3040400.00.00
Unipolar wire - 6 m / Cavo unipolare - 6 m
Not included
1 Piece - Max 60V DC
Max 3 modules
1A4730000.00.00
Suspension kits / Kit di sospensione
Recessed suspension kit for 12,5 mm plasterboard / Kit di sospensione da incasso per cartongesso 12,5 mm
Not included
Matt White
For elettrical cables - 1 Piece
Plasterboard cut-out Ø 44 mm
Minimum space for mounting 70 mm
1X0000300.02.00
Matt Black
For elettrical cables - 1 Piece
Plasterboard cut-out Ø 44 mm
Minimum space for mounting 70 mm
1X0000400.02.00
Ceiling suspension kit / Kit di sospensione da soffitto
Not included
Matt White
For elettrical cables - 1 Piece
1X0010300.02.00
Matt Black
For elettrical cables - 1 Piece
1X0010400.02.00
