323
322
Davide Groppi / 2023
ASINTOTO
ASINTOTO
Davide Groppi / 2023
Optional accessories / Accessori opzionali
Installation kits / Kit d'installazione
Circular plasterboard panel 12,5 mm / Botola circolare per cartongesso 12,5 mm
Not included
Standard
Cut-out 400x400 mm
Minimum space for mounting Ø 115 mm
1A4520000.00.00
Suspension kits / Kit di sospensione
Recessed suspension kit for 12,5 mm plasterboard / Kit di sospensione da incasso per cartongesso 12,5 mm
Not included
Matt White
For elettrical cables - 1 Piece
Plasterboard cut-out Ø 44 mm
Minimum space for mounting 70 mm
1X0000300.04.00
Matt Black
For elettrical cables - 1 Piece
Plasterboard cut-out Ø 44 mm
Minimum space for mounting 70 mm
1X0000400.04.00
Ceiling suspension kit / Kit di sospensione da soffitto
Not included
Matt White
For elettrical cables - 1 Piece
1X0010300.04.00
Matt Black
For elettrical cables - 1 Piece
1X0010400.04.00
Wall adapter plate / Piastra di adattamento da parete
Not included
Matt White
For mounting on brick masonry walls
1X0050300.01.00
Other accessories / Altri accessori
Magnetic weight / Peso magnetico
Not included
Matt Black
For sloped installation
1A4710400.00.00
Ceiling / Indirect / Indoor
Material
Metal - Methacrylate
Finish
.27 Gravity Black
Note
Ceiling luminaire. Disc with gravity black finish. Magnetic weight available
for disc tilting. Black cable.
Apparecchio illuminante da soffitto. Disco con finitura gravity black.
Disponibile un peso magnetico per l’orientamento inclinato del disco.
Cavo nero.
ASINTOTO
18W
Max 500mA DC
2700K - 1435lm / 3000K - 1478lm
CRI >90
Driver not included
Gravity Black - 2700K
1A4072700.27.20
Gravity Black - 3000K
1A4072700.30.20
Compulsory accessories / Accessori obbligatori
Drivers / Alimentatori
Driver / Alimentatore
Not included
220-240V(100-127V)
500mA/20W(15W)/IP20/DALI
1Z0241180.500
Driver / Alimentatore
Not included
220-240V(100-127V)
500mA/20W(15W)/IP20/PUSH - 1-10V
1Z0240870.500
Driver / Alimentatore
Not included
220-240V
500mA/20W/IP20/TRIAC/IGBT
1Z0240850.500
