Maurizio Mancini / 2015
MASAI
MASAI
Maurizio Mancini / 2015
Compulsory accessories
Drivers
Driver
Not included
220-240V(100-127V)
24V/22W(12W)/IP20/ON/OFF
MASAI 2
1Z0240410
Driver
Not included
120-277V
24V/60W/IP20/TRIAC - 1-10V
MASAI 2
1Z2020040
Controller
Not included
Matt Black
DALI - PUSH - 0/1-10V - IP20
MASAI 2
1Z2170020
Optional accessories
Suspension kits
Sloped ceiling suspension kit
Not included
Nickel plated - 1 Piece
1A0510000.00.00
Recessed suspension kit for 0.49" plasterboard
Not included
Matt White
For suspension cables - 1 Piece
Plasterboard cut-out Ø 1.73"
Minimum space for mounting 2.76"
1X0000300.03.00
Matt Black
For suspension cables - 1 Piece
Plasterboard cut-out Ø 1.73"
Minimum space for mounting 2.76"
1X0000400.03.00
Ceiling suspension kit
Not included
Matt White
For suspension cables - 1 Piece
1X0010300.03.00
Matt Black
For suspension cables - 1 Piece
1X0010400.03.00
Wall adapter plate
Not included
Matt White
For mounting on brick masonry walls
1X0050300.01.00
304 Stainless steel suspension cable
Not included
Lenght 393.70"
1A1680000.00.00
Floor-Suspension / Indirect / Indoor
Material
Brass - Methacrylate
Finish
.03 Matt White
.04 Matt Black
.08 Brushed Brass
Note
Floor luminaire with ceiling fixing. Adjustable along the vertical axis. Matt
white rose. AISI 304 stainless steel suspension cable. Dimmer on the
cable. Transparent cable. MASAI 2: version with power cable only and
without driver.
MASAI 1
Driver with plug version
15,5W
120V - 60Hz
2700K - 600lm / 3000K - 619lm
CRI >90
Driver integrated
Dimmer on board
Matt White - 2700K - Dimmer on board
1A2720303.27.06
Matt White - 3000K - Dimmer on board
1A2720303.30.06
Matt Black - 2700K - Dimmer on board
1A2720403.27.06
Matt Black - 3000K - Dimmer on board
1A2720403.30.06
Brushed Brass - 2700K - Dimmer on board
1A2720803.27.06
Brushed Brass - 3000K - Dimmer on board
1A2720803.30.06
MASAI 2
Remote driver version
13W
120V - 60Hz
2700K - 600lm / 3000K - 619lm
CRI >90
Driver not included
Matt White - 2700K
1A2720303.27.20
Matt White - 3000K
1A2720303.30.20
Matt Black - 2700K
1A2720403.27.20
Matt Black - 3000K
1A2720403.30.20
Brushed Brass - 2700K
1A2720803.27.20
Brushed Brass - 3000K
1A2720803.30.20
