285
284
/ 2001
SPOT
SPOT
/ 2001
Optional accessories
Other accessories
Accessory holder + Soft filter + Honeycomb louvre
Not included
Matt Black
1X0070400.04.00
Accessory holder + Elliptical filter
Not included
Matt Black
1X0070400.05.00
Blue filter
Not included
Standard
Compulsory with
1X0070400.04.00 / 1X0070400.05.00
1X0070000.06.00
Red filter
Not included
Standard
Compulsory with
1X0070400.04.00 / 1X0070400.05.00
1X0070000.07.00
Yellow filter
Not included
Standard
Compulsory with
1X0070400.04.00 / 1X0070400.05.00
1X0070000.08.00
Horizontal directional fins
Not included
Matt Black
1X0070400.01.00
Cylindrical screen
Not included
Matt Black
1X0070400.02.00
Cone 45°
Not included
Matt Black
1X0070400.03.00
Compulsory accessories
LED modules
DG111 LED Module
Not included
13,5W - 15° - 400mA DC
2700K - 1318lm - CRI >90
Energy Efficiency F - Dimmable
SPOT
1A4700003.27.20
13,5W - 15° - 400mA DC
3000K - 1345lm - CRI >90
Energy Efficiency F - Dimmable
SPOT
1A4700003.30.20
DG111 LED module
Not included
13,5W - 22° - 400mA DC
2700K - 1487lm - CRI >90
Energy Efficiency F - Dimmable
SPOT
1A3890003.27.20
13,5W - 22° - 400mA DC
3000K - 1556lm - CRI >90
Energy Efficiency F - Dimmable
SPOT
1A3890003.30.20
DG111 LED module
Not included
13,5W - 36° - 400mA DC
2700K - 1446lm - CRI >90
Energy Efficiency F - Dimmable
SPOT
1A3900003.27.20
13,5W - 36° - 400mA DC
3000K - 1512lm - CRI >90
Energy Efficiency F - Dimmable
SPOT
1A3900003.30.20
DG111 LED Module
Not included
11,7W - 15° - 350mA DC
2700K - 1068lm - CRI >90
Energy Efficiency F - Dimmable
SPOT ENDLESS /
SPOT ENDLESS CASAMBI
1A4700003.27.20
11,7W - 15° - 350mA DC
3000K - 1091lm - CRI >90
Energy Efficiency F - Dimmable
SPOT ENDLESS /
SPOT ENDLESS CASAMBI
1A4700003.30.20
DG111 LED module
Not included
11,7W - 22° - 350mA DC
2700K - 1508lm - CRI >90
Energy Efficiency F - Dimmable
SPOT ENDLESS /
SPOT ENDLESS CASAMBI
1A3890003.27.20
11,7W - 22° - 350mA DC
3000K - 1578lm - CRI >90
Energy Efficiency F - Dimmable
SPOT ENDLESS /
SPOT ENDLESS CASAMBI
1A3890003.30.20
DG111 LED module
Not included
11,7W - 36° - 350mA DC
2700K - 1266lm - CRI >90
Energy Efficiency F - Dimmable
SPOT ENDLESS /
SPOT ENDLESS CASAMBI
1A3900003.27.20
11,7W - 36° - 350mA DC
3000K - 1323lm - CRI >90
Energy Efficiency F - Dimmable
SPOT ENDLESS /
SPOT ENDLESS CASAMBI
1A3900003.30.20
