TECHNICAL INFORMATION
CUSTOM
CENTRAL ROD SUSPENSION
CONNECTION BOX
DIMENSIONS
REFERENCE
+
Ø102
40
600 mm
SC20.60
800 mm
SC20.80
1000 mm
SC20.100
SUSPENSION KIT 5m
5m
SC05.SA
SUSPENSION KIT 7m
7m
SC07.SA
SUSPENSION KIT 10m
10m
SC10.SA
PENDANT COMPONENTS
SEGMENT 1
Ø650 90º
126EG1B112O
SEGMENT 7
843 mm
126EH1B112O
SEGMENT 8
1124 mm
126EJ1B112O
SEGMENT 9
1405 mm
126EL1B112O
SEGMENT 10
1686 mm
126EN1B112O
SEGMENT 11
1967 mm
126EP1B112O
SEGMENT 12
2248 mm
126ER1B112O
SEGMENT 2
Ø650 180º
126EI1B112O
SEGMENT 4
Ø950 180º
126EM1B112O
SEGMENT 3
Ø950 90º
126EK1B112O
SEGMENT 5
Ø1250 90º
126EO1B112O
SEGMENT 6
Ø1250 180º
126EQ1B112O
SECTION
A
B
C
D
E
F
G
H
I
SEGMENT
4
6
6
3
3
2
9
1
3
A
C
B
D
E
H
G
F
I
BUILD YOUR PERFECT LUMINAIRE (EXAMPLE)
ON DEMAND OPTIONS
Special
finishes
Special color
temperatures
Number
switches
Custom
dimensions
Emergency
lighting
Motion
detection
Wireless
control options
Surface/Wall sfc.
up light
POWER STANDARD
90º
180º
90º
180º
90º
180º
Ø650 90º
Ø650 180º
Ø950 90º
Ø950 180º
Ø1250 90º
Ø1250 180º
24 V
6 W
403 - 448 - 493 lm
12 W
807 - 896 - 986 lm
9 W
590 - 655 - 721 lm
17 W
1179 - 1310 - 1441 lm
11 W
776 - 862 - 948 lm
22 W
1552 - 1724 - 1896 lm
700 mA
15 W
1481 - 1556 - 1633 lm
29 W
2963 - 3111 - 3267 lm
29 W
2469 - 2593 - 2722 lm
49 W
4938 - 5185 - 5444 lm
29 W
2963 - 3111 - 3267 lm
29 W
6420 - 6741 - 7078 lm
Opal -
Microprismatic
2700 K
126EG
1
2
126EI
1
2
126EK
1
2
126EM
1
2
126EO
1
2
126EQ
1
2
3000 K
126EG
1
3
126EI
1
3
126EK
1
3
126EM
1
3
126EO
1
3
126EQ
1
3
4000 K
126EG
1
5
126EI
1
5
126EK
1
5
126EM
1
5
126EO
1
5
126EQ
1
5
843
1124
1405
1686
1967
2248
.03
.04
.05
.06
.07
.08
24 V
10 W
666 - 740 - 814 lm
13 W
888 - 987 - 1086 lm
16 W
1110 - 1234 - 1357 lm
19 W
1332 - 1480 - 1628 lm
22 W
1551 - 1724 - 1896 lm
26 W
1776 - 1924 - 2171 lm
700 mA
29 W
2963 - 3111 - 3267 lm
39 W
3950 - 4148 - 4355 lm
49 W
4938 - 5185 - 5444 lm
59 W
5926 - 6222 - 6533 lm
69 W
6913 - 7259 - 7622 lm
78 W
7901 - 8296 - 8711 lm
Opal -
Microprismatic
2700 K
126EH
1
2
126EJ
1
2
126EL
1
2
126EN
1
2
126EP
1
2
126ER
1
2
3000 K
126EH
1
3
126EJ
1
3
126EL
1
3
126EN
1
3
126EP
1
3
126ER
1
3
4000 K
126EH
1
5
126EJ
1
5
126EL
1
5
126EN
1
5
126EP
1
5
126ER
1
5
Add 22 mm when the luminaire is closed (11 mm per end cap).
