luminaire finishes
aluminium | PC
RAFTER wall washer LED trim
RAFTER mini points move LED
37976-L930-R1-00-12
37977-L930-R1-00-12
37978-L930-R1-00-12
38065-M930-FB-00-12
38066-M930-FB-00-12
147mm
279mm
412mm
143mm
255mm
5W - 15W (L) | 5W - 15W (A)
584lm – 1752lm
8.5W - 17W (M) | 8.5W - 17W (A)
778lm – 1556lm
2700K (27) | 3000K (30) | 4000K (40)
3000K (30) | 4000K (40)
power:
flux:
optics:
CCT:
control:
230V
230V
CRI
>90
CRI
>90
dim opt
dim opt
IP20
IP20
white -_W
black -_B
optics finishes
main material
wall washer (R1)
37° (F_)
ON/OFF (00) | DALI (DA) | require driver (CC)*
ON/OFF (00) | Phase-Control (PH) | DALI (DA) | require driver (CC)*
RAFTER
only for RAFTER mini points
* Protection class, input voltage and IP rating for CC luminaires vary from above table.
138mm
271mm
403mm
134mm
247mm
35xLmm | Hmin: 70mm
43xLmm | Hmin: 50mm
cat. n°
cat. n°
length
length
instal
instal
CC driver
CC driver
(W) 350mA | 14.1V
(X) 350mA | 28.2V
(Y) 350mA | 42.3V
(AB) 500mA | 17.2V
(AC) 500mA | 34.4V
recessed
surface p. 206-212
suspended p. 328-330
track p. 430-438
wall p. 494
systems p. 618
Data for standard LED product is shown for LED light source 3000K. Other variants are available on our website.
