| 169
Monochrome illumination
Dynamic illumination
Specifications
LED
3 POW-LED
WATT
total 5 W
POWER
CC 350 mA
BEAM
30° medium
CABLE
UW, 2x0,5 qmm
TEMP.
<40°C
Control gear
Details
5.0635.65.03 max 1
5.0635.65.20 max 2-4
➜ 214
Beam Angle 30° (medium)
Beam Angle 30° (medium)
Beam Angle omogeneous diffuse
Beam Angle homogeneous diffuse
Cover
#
Color
Lumen
Round Cover
4.0026.20.11
6000K cold white
495 lm
4.0026.20.12
3000K warm white
405 lm
4.0026.20.13
4500K neutral white
465 lm
Square Cover
4.0026.40.11
6000K cold white
495 lm
4.0026.40.12
3000K warm white
405 lm
4.0026.40.13
4500K neutral white
465 lm
Specifications
LED
1 POW-LED
WATT
total 2 W
POWER
CC 350 mA
BEAM
homogen diffus
CABLE
UW, 2x0,5 qmm
TEMP.
<40°C
Control gear
Details
5.0635.65.03 max 3
5.0635.65.20 max 5-12
➜ 214
Cover
#
Color
Lumen
Round Cover
4.0025.20.11
6000K cold white
165 lm
4.0025.20.12
3000K warm white
135 lm
4.0025.20.13
4500K neutral white
155 lm
Square Cover
4.0025.40.11
6000K cold white
165 lm
4.0025.40.12
3000K warm white
135 lm
4.0025.40.13
4500K neutral white
155 lm
Specifications
LED
3 POW-LED
WATT
all on 5 W
POWER
CC 350 mA
BEAM
30° medium
CABLE
UW, 6x0,5 qmm
TEMP.
<40°C
Specifications
LED
1 Multichip POW-LED
WATT
all on 5 W
POWER
CC 350 mA
BEAM
diffus
CABLE
UW, 6x0,5 qmm
TEMP.
<40°C
Control gear
Details
5.0635.09.16 max 4
5.0635.09.50 max 5-12
➜ 220
Control gear
Details
5.0635.09.16 max 4
5.0635.09.50 max 5-12
➜ 220
Cover
#
Color
Lumen
Round Cover
4.0026.20.19
RGB
Square Cover
4.0026.40.19
RGB
Cover
#
Color
Lumen
Round Cover
4.0025.20.19
RGB
Square Cover
4.0025.40.19
RGB
IP67 IK08
STAINLESS
STEEL V4A
1.4571
316Ti
ALU
3.000 K
4.500 K
6.000 K
RGB
CONSTANT
CURRENT
KONSTANT
STROM
DALI
1-10 V
OPTIONAL
DIMM
CABLE
INCL.
650kg
Recessed spotlight | 4.0026
