| 153
· Protection class IP68 – for a water depth of up to 3 m
· Protection class IP69 - protection against high pressure and high jet water
temperatures
· Entirely made of stainless steel 316Ti
· Mounting foot adjustable through 180° or 90°
···
· POW-LED cold white, warm white, neutral white, 230 V
···
· Cable gland PG13,5, marine grade 316Ti stainless steel
· Temperature-resistant silicon seal
· Toughened safety glass
· Supplied with light source and 3 m of underwater cable
Monochrome illumination
Additional parts
anti-glare louvre
black, for POW-LED
4.0003.02.01
glass disc, frosted
for softer light
distribution (light loss
approx. -15%)
4.0066.01.00
spike
Stainless steel,
395 mm, for mounting
foot 90°
4.0305.50.00
Anti-glare ring
Stainless steel 316Ti,
ø 178 mm,
length 203 mm
9.0192.00.70
Cover
#
Color
Lumen
LED
Watt
Power
Beam
Cable
Standard |
180° adjustable
4.0195.18.01
6000K cold white
1980 lm
12 POW-LED
total 15 W
230V
30° medium
UW, 3x1,5 qmm
4.0195.18.02
3000K warm white
1620 lm
4.0195.18.03
4500K neutral white
1860 lm
Standard |
90° adjustable
4.0195.90.01
6000K cold white
1980 lm
4.0195.90.02
3000K warm white
1620 lm
4.0195.90.03
4500K neutral white
1860 lm
IP68
IP69
IK11
STAINLESS
STEEL V4A
1.4571
316Ti
3.000 K
4.500 K
6.000 K
230 V
CABLE
INCL.
90°
180°
205
210
210
170
212
170
4.0195
Surface-mounted Spotlight
Under- and overwater operations
Notes
· Beam Angle: POW-LED: 10°, 30°, 45°
· Not to be used at accessible areas. (mains voltage 230V)
· SALINE version possible - Article number with an additional „S“ at the end
· Versions with HIT-TC-CE lamp available
