150
· Protection class IP68 – for a water depth of up to 3 m
· Protection class IP69 - protection against high pressure and
high jet water temperatures
· Entirely made of stainless steel 316Ti 1.4571
· Mounting foot adjustable through 180°
···
· POW-LED cold white, warm white, neutral white
· Multichip POW-LED RGB
· Operating mode: constant current
· Rotationally symmetric light distribution
···
· Cable pressure sleeve, V4A stainless steel
· Temperature-resistant silicon seal
· Toughened safety glass
· Supplied with UW-cable (3 m) already connected
Additional parts
spike
150 mm
4.0011.50.00
Anti-glare ring
V4A-Edelstahl,
ø 40 mm, Länge 50 mm
9.0011.00.70
4.0011.15
Surface-mounted Spotlight
IP68
IP69
IK07
STAINLESS
STEEL V4A
1.4571
316Ti
3.000 K
4.500 K
6.000 K
COLOR
RGB
CONSTANT
CURRENT
KONSTANT
STROM
CABLE
INCL.
180°
DALI
1-10 V
OPTIONAL
DIMM
max 3m
47
35
37
· POW-LED with beam angle spot 10°, medium 30°, wide 45°, flood 90° and elliptical 15x40°
· POW-LED, series-connected
· SALINE version possible - Article number with an additional „S“ at the end
#
Color
Lumen
LED
Watt
Power
Beam
Cable
Connect ➜ 208
4.0011.15.01
6000K cold white
165 lm
1 POW-LED
total 2 W
CC 350 mA
10° spot
UW, 2x0,5 qmm
5.0635.65.03 max 3
5.0635.65.20 max 4-12
5.0635.03.30 max 7 (14*)
5.0635.03.31 max 7 (14*)
4.0011.15.02
3000K warm white
135 lm
4.0011.15.03
4500K neutral white
155 lm
4.0011.15.09
RGB
1 Multichip POW-LED
all on 5 W
CC 350 mA
120° flood
UW, 6x0,5 qmm
5.0635.09.16 max 4
5.0635.09.24 max 5-8
5.0635.09.50 max 5-12
Notes
*Only for areas without people inside the water
Under- and overwater operations
Underwater environments only
