| 105
4.0299.73
Retrofit Spotlight
· Protection class IP68 – up to 5m water depth
· Protection class IP69 - protection against high pressure and
high jet water temperatures
· Special corrosion-proof version made marine grade
904L stainless steel 1.4539
· For pools with increased saltwater concentration (up to 3.5 %)
· Round attachment cover, made of stainless steel 904L, height 13 mm
···
· Operating mode: constant current
· POW-LED cold white, warm white, neutral white
· POW-LED royal blue
· Multichip POW-LED RGB
· Operating mode: constant voltage
· Multichip POW-LED RGB-W
· Rotationally symmetric light distribution
···
· Constant-current power source/RGB controller ordered separately
· Supplied with 3 m of special underwater cable
Additional parts
built in pot of 316L
stainless steel with
1,5 m cable duct, cable
entry from side, saline
version
4.0299.73.00
mounting bracket
required for
Replacement, saline
version
9.0299.73.10
mounting plate
Saline version, made
of V4A-stainless steel
1.4539, round,
ø 310 mm
9.0299.20.73
mounting plate
Saline version, made
of stainless steel 904L
1.4539, square,
290 x 290 mm
9.0299.40.73
glass disc, frosted
for softer light
distribution (light loss
approx. -15%)
50.4.00109.138
IP68
IP69
IK08
STAINLESS
STEEL V4A
1.4539
904L
3.000 K
4.500 K
6.000 K
BLUE
RGB
RGB-W
CONSTANT
CURRENT
CONSTANT
VOLTAGE
DALI
1-10 V
OPTIONAL
DIMM
CABLE
INCL.
max 5m
183
226
95
127
60
258
258
13
Monochrome and dynamic illumination
#
Color
Lumen
LED
Watt
Power
Beam
Cable
Connect ➜ 208
4.0299.73.11
6000K cold white
3450 lm
15 POW-LED
total 42 W
CC 3500mA
@12 V-DC
120° flood
UW, 2x2,5 qmm
5.0670.00.15 max 1
5.0670.11.15 max 1
4.0299.73.12
3000K warm white
2850 lm
4.0299.73.13
4500K neutral white
3225 lm
4.0299.73.16
royal blue
650 mW/LED
4.0299.73.19
RGB
9 Multichip
POW-LED
all on 85 W
CC 700mA
@12 V-DC
120° flood
UW, 6x1,0 +
2x0,5 qmm
5.0670.19.24 max 1
4.0299.73.41
RGB-CW cold white 6000K
coldwhite: 1590 lm
6 Multichip
POW-LED
all on 60 W
CV 12 V-DC
diffus
UW, 2x2,5 +
4x0,5 qmm
5.0670.09.52 max 2
4.0299.73.42
RGB-WW warm white 3000K
warmwhite: 1220 lm
4.0299.73.43
RGB-NW neutral white 4500K
neutralwhite: 1390 lm
4.0299.73.44
RGB amber
Notes
· POW-LED with beam angle spot 10°, medium 30° and wide 45° on request
· POW-LED monochrome, single colour in green, red, amber, turquoise, capriblue
· Version for the replacement of existing PAR56 lights. All common manufacturers available (cover with different hole pitch circles).
· Version without Scatter disc at RGB-W
· A new mounting bracket is required (9.0299.73.10)
Underwater environments only
