| 101
4.0271
Swimming pool Light
Monochrome and dynamic illumination
· Protection class IP68 – up to 3m water depth
· Entirely made of stainless steel 316Ti 1.4571
· Round attachment cover, made of stainless steel 316Ti, height 13 mm
· For all standard pool types
···
· QT12 or QT16 light sources
· POW-LED white 12 V-DC
· POW-LED capriblue 12 V-DC
· POW-LED RGB 12 V-DC
· POW-LED white 24 V-DC
· POW-LED RGB 24 V-DC
· Optimation of beam angle character
· POW-LED-Platine temperature control (NTC)
· Beam angle: 80° symmetric/horizontal and 45° asymmetric/vertical
(halogen)
···
· Light source can be changed without draining the water (halogen)
· Type 4.0272 with frosted glass for soft light distribution
(light losses approx. 15 %)
· Supplied with light source and special underwater cable already connected
Additional parts
pressure flange
for thin-walled pools
or pools with fitted
plastic foil
4.0274.00.25
gluing and pressure
flange
for adhesive/foil
coating with pressure
flange
4.0274.55.25
gluing flange
for adhesive/foil
coating
4.0274.55.55
mounting plate
for replacement to
Wibre, square, grade
316, 290 x 290 x 11 mm
9.8167.00.00
built in pot of 316L
stainless steel with 1,5m
cable duct, cable entry
from side
4.0274.00.00
built in pot of 316L
stainless steel with 1,5m
cable duct, cable entry
from behind
4.0274.00.50
mounting plate
for replacement to
Wibre, round, grade
316, ø 302 x 9 mm
9.8267.00.00
IP68
STAINLESS
STEEL V4A
1.4571
316Ti
POW-LED
INCL.
3.000 K
4.500 K
6.000 K
RGB
CONSTANT
CURRENT
KONSTANT
STROM
QT12
QT16
12 V-AC
30 V-DC
CABLE
INCL.
max 3m
258
183
102
226
62
258
95
13
Notes
· Monochrome POW-LED available in red, green,
blue, amber and warm white
· An installation housing is required for a new
installation. Please order separately.
· Must only be operated with a WIBRE power
supply or controller
· Saline version (4.0273) and flush version
(4.0275) available - www.wibre.de
#
Lumen
LED
Watt
Power
Beam
Cable
Connect ➜ 208
4.0271.00.01
6000K cold white
2700 lm
18 POW-LED
total 50 W
CC 700 mA
@24 V-DC
asym-
metrical
UW, 2x2,5 qmm
5.0670.00.40 max 1
4.0271.00.09
RGB
24 POW-LED
all on 30 W
CC 350 mA
@24 V-DC
UW, 6x1,0 +
2x0,5 qmm
5.0635.09.24 max 1
4.0271.00.11
6000K cold white
4050 lm
27 POW-LED
total 85 W
CC 700 mA
@12 V-DC
asym-
metrical
UW, 6x1,0 +
2x0,5 qmm
5.0670.11.24 max 1
4.0271.00.12
3000K warm white
3510 lm
4.0271.00.13
4500K neutral white
3780 lm
4.0271.00.26
capri blue (9 x blue, 9 x green, 9 x white)
4.0271.00.19
RGB
all on 85 W
5.0670.19.24 max 1
4.0271.03.10
3000K
2.200lm
QT12
100W
12V-AC
asym-
metrical UW, 2x2,5 qmm
5.0100.00.00 max 1
5.0311.00.00 max 2
4.0271.03.17
3000K
5.100lm
175W
5.0311.00.00 max 1
5.0103.00.00 max 2
4.0271.03.20
3000K
5.800lm
200W
30V-DC
5.0410.00.01 max 1
5.0420.00.01 max 2
4.0271.03.40
3000K
11.600lm
400W
5.0420.00.01 max 1
Underwater environments only
