749
SPAN 24 BATH
P 526
ITEM NUMBER
Chrome
700BCSPANB2C-LED930 (120V, Direct/Indirect)
700BCSPANB2C-LED930-277 (277V, Direct/Indirect)
Satin Nickel
700BCSPANB2S-LED930 (120V, Direct/Indirect)
700BCSPANB2S-LED930-277 (277V, Direct/Indirect)
Nightshade Black
700BCSPANB2B-LED930 (120V, Direct/Indirect)
700BCSPANB2B-LED930-277 (277V, Direct/Indirect)
Plated Brass
700BCSPANB2BR-LED930 (120V, Direct/Indirect)
700BCSPANB2BR-LED930-277 (277V, Direct/Indirect)
SIZE
H: 4.2" | L: 24.6" | D: 5.5"
Mounts horizontal or vertical
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 25.5W
Delivered Lumens: 1214
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV dimmers
277V compatible with 0-10V dimmers
24.6"
625 mm
5.5"
127 mm
5"
127 mm
.6"
15 mm
1.1"
28 mm
4.2"
107 mm
.6"
15 mm
SPAN 36 BATH
P 528
ITEM NUMBER
Chrome
700BCSPANB3C-LED930 (120V, Direct/Indirect)
700BCSPANB3C-LED930-277 (277V, Direct/Indirect)
Satin Nickel
700BCSPANB3S-LED930 (120V, Direct/Indirect)
700BCSPANB3S-LED930-277 (277V, Direct/Indirect)
Nightshade Black
700BCSPANB3B-LED930 (120V, Direct/Indirect)
700BCSPANB3B-LED930-277 (277V, Direct/Indirect)
Plated Brass
700BCSPANB3BR-LED930 (120V, Direct/Indirect)
700BCSPANB3BR-LED930-277 (277V, Direct/Indirect)
SIZE
H: 5.5" | L: 35.3" | D: 5.5"
Mounts horizontal or vertical
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 34.3W
Delivered Lumens: 1275
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
277V compatible with 0-10V dimmers
35.3"
897 mm
5.5"
140 mm
6"
152 mm
5.5"
140 mm
BATH
SPAN 48 BATH
P 530
ITEM NUMBER
Chrome
700BCSPANB4C-LED930 (Direct/Indirect)
Nightshade Black
700BCSPANB4B-LED930 (Indirect)
Plated Brass
700BCSPANB4BR-LED930 (Indirect)
Satin Nickel
700BCSPANB4S-LED930 (Direct/Indirect)
SIZE
H: 5.5" | L: 46.8" | D: 5.5"
Mounts horizontal or vertical
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 45.2W
Delivered Lumens: 1581
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
277V compatible with 0-10V dimmers
46.8"
1189 mm
6"
152 mm
5.5"
140 mm
5.5"
140 mm
TRIS 3-LIGHT BATH
P 532
ITEM NUMBER
Chrome
700BCTRS3C-LED930 (120V)
700BCTRS3C-LED930-277 (277V)
Aged Brass
700BCTRS3R-LED930 (120V)
700BCTRS3R-LED930-277 (277V)
Satin Nickel
700BCTRS3S-LED930 (120V)
700BCTRS3S-LED930-277 (277V)
SIZE
H: 4.3" | L: 25.6" | D: 3.4"
Mounts horizontal and vertical
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 18W
Delivered Lumens: 671
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
277V compatible with 0-10V dimmers
ADA compliant
25.6"
650 mm
5"
127 mm
4.3"
109 mm
3.4"
86 mm
