745
BAU 24 BATH
P 518
ITEM NUMBER
Natural Brass
700BCBAU24NB-LED930 (120V)
700BCBAU24NB-LED930-277 (277V)
Nightshade Black
700BCBAU24B-LED930 (120V)
700BCBAU24B-LED930-277 (277V)
Polished Nickel
700BCBAU24N-LED930 (120V)
700BCBAU24N-LED930-277 (277V)
SIZE
H: 5" | L: 24" | D: 1.8"
Mounts horizontal or vertical
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 12.2W
Delivered Lumens: 295
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
Triac and 0-10V dimmers
ADA Compliant
24"
610 mm
1.8"
46 mm
5"
127 mm
4.3"
109 mm
DOBSON II 3-LIGHT BATH SHALLOW
P 540
ITEM NUMBER
Chrome
700BCDBS3HC-LED930 (120V)
700BCDBS3HC-LED930-277 (277V)
Matte Black
700BCDBS3HB-LED930 (120V)
700BCDBS3HB-LED930-277 (277V)
SIZE
H: 6.3" | L: 19.5" | D: 3.3"
Mounts horizontal or vertical
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 35W
Delivered Lumens: 2135
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV and Triac
dimmers; 277V compatible with 0-10V dimmers
ADA compliant
3.3"
84 mm
19.5"
495 mm
6.3"
160 mm
5"
127 mm
4.25"
108 mm
ELLIS 24 BATH
P 546
ITEM NUMBER
Chrome
700BCELI24C-LED930 (120V)
700BCELI24C-LED930-277 (277V)
Satin Nickel
700BCELI24S-LED930 (120V)
700BCELI24S-LED930-277 (277V)
SIZE
H: 4.3" | L: 24" | D: 4.2"
Mounts horizontal or vertical
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 23.7W
Delivered Lumens: 1909
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV and Triac
dimmers; 277V compatible with 0-10V dimmers
24"
610 mm
4.2"
107 mm
4.3"
109 mm
6.5"
165 mm
ELLIS 36 BATH
P 546
ITEM NUMBER
Chrome
700BCELI36C-LED930 (120V)
700BCELI36C-LED930-277 (277V)
Satin Nickel
700BCELI36S-LED930 (120V)
700BCELI36S-LED930-277 (277V)
SIZE
H: 4.3" | L: 36" | D: 4.2"
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 36W
Delivered Lumens: 1995
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV and Triac
dimmers; 277V compatible with 0-10V dimmers
36"
914 mm
4.2"
107 mm
6.5"
165 mm
4.3"
109 mm
FINN 24 BATH
P 544
ITEM NUMBER
Antique Bronze
700BCFINN24Z-LED930 (Antique Bronze)
Satin Nickel
700BCFINN24S-LED930 (Satin Nickel)
SIZE
H: 4.3" | L: 25" | D: 2.3"
Mounts horizontal or vertical
LAMPING
Integrated LED
Voltage: 120V-277V
Total Watts: 24W
Delivered Lumens: 1252
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV, Triac and 0-10V
dimmers; 277V compatible with 0-10V dimmers
ADA compliant
25"
635 mm
2.3"
58 mm
5"
127 mm
4.3"
110 mm
FINN 36 BATH
P 524
ITEM NUMBER
Satin Nickel
700BCFINN36S-LED930
SIZE
H: 4.3" | L: 36.3" | D: 2.3"
Mounts horizontal or vertical
LAMPING
Integrated LED
Voltage: 120V-277V
Total Watts: 33W
Delivered Lumens: 1724
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV, Triac and 0-10V
dimmers; 277V compatible with 0-10V dimmers
ADA compliant
36.3"
922 mm
2.3"
58 mm
5"
127 mm
4.3"
110 mm
BATH
