741
VETRA SCONCE
P 482
ITEM NUMBER
Linen/Satin Nickel
700WSVTRLNS (No Lamp)
700WSVTRLNS-LED927 (T6 Lamp)
SIZE
H: 13.2" | W: 4.9" | D: 3.9"
Mounts vertical only
LAMPING
No Lamp Option
Rated for (1) 25W max E12 candelabra base lamp
LED E12 Base T6 Lamp
Voltage: 120V
Total Watts: 2W
Delivered Lumens: 160
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
ADA compliant
4.9"
125 mm
3.9"
100 mm
13.2"
336 mm
VIAGGIO SCONCE
P 468
ITEM NUMBER
Opal/Brass
700WSVGOOR (No Lamp)
700WSVGOOR-LED930 (G9 Lamp)
Smoke/Polished Nickel
700WSVGOSN (No Lamp)
700WSVGOSN-LED927 (T6 Lamp)
SIZE
H: 26.5" | W: 19" | D: 9.1"
Mounts up only
LAMPING
No Lamp Option
Opal rated for (6) 5W max G9 bi-pin lamps
Mirrored Smoke rated for (6) 5W max
candelabra base LED E12 lamps
LED G9 Bi-Pin Lamps (Opal/Brass)
Voltage: 120V
Total Watts: 6 x 5W
Delivered Lumens: 2021
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
LED E12 Base T6 Lamps (Smoke/Polished Nickel)
Voltage: 120V
Total Watts: 6 x 2W
Delivered Lumens: 900
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
19"
483 mm
9.1"
231 mm
26.5"
673 mm
VOTO ROUND SCONCE
P 493
ITEM NUMBER
Antique Bronze
700WSVOTRCZ-LED930 (120V)
700WSVOTRCZ-LED930-277 (277V)
Black
700WSVOTRCB-LED930 (120V)
700WSVOTRCB-LED930-277 (277V)
Satin Nickel
700WSVOTRCS-LED930 (120V)
700WSVOTRCS-LED930-277 (277V)
White
700WSVOTRCW-LED930 (120V)
700WSVOTRCW-LED930-277 (277V)
SIZE
H: 5" | W: 4.3" | D: 3.9"
May be mounted horizontally or vertically
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 9W
Delivered Lumens: 424
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV and Triac
dimmers; 277V compatible with 0-10V dimmers
ADA compliant
4.3"
109 mm
3.9"
99 mm
5"
127 mm
VOTO SQUARE SCONCE
P 492
ITEM NUMBER
Antique Bronze
700WSVOTSCZ-LED930 (120V)
700WSVOTSCZ-LED930-277 (277V)
Black
700WSVOTSCB-LED930 (120V)
700WSVOTSCB-LED930-277 (277V)
Satin Nickel
700WSVOTSCS-LED930 (120V)
700WSVOTSCS-LED930-277 (277V)
White
700WSVOTSCW-LED930 (120V)
700WSVOTSCW-LED930-277 (277V)
ITEM NUMBER
SIZE
H: 5" | W: 4.3" | D: 3.9"
Mounts horizontal or vertical
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 12.4W
Delivered Lumens: 424
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV and Triac
dimmers; 277V compatible with 0-10V dimmers
ADA compliant
4.3"
109 mm
3.9"
99 mm
5"
127 mm
SCONCE
