PRODUCT SPECIFICATIONS
Additional products and options are available at techlighting.com
KAMDEN SCONCE
P 490
ITEM NUMBER
Chrome
700BCKMD1C-LED930 (120V)
700BCKMD1C-LED930-277 (277V)
Satin Nickel
700BCKMD1S-LED930 (120V)
700BCKMD1S-LED930-277 (277V)
SIZE
H: 4.7" | W: 5" | D: 4.7"
Mounts horizontal or vertical
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 13W
Delivered Lumens: 608
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
277V compatible with 0-10V dimmers
4.7"
119 mm
5"
127 mm
4.7"
109 mm
KENWAY SCONCE
P 464
ITEM NUMBER
Chrome
700WSKNWC-LED930 (120V)
700WSKNWC-LED930-277 (277V)
Matte Black
700WSKNWB-LED930 (120V)
700WSKNWB-LED930-277 (277V)
SIZE
H: 17" | W: 4.3" | D: 2.1"
Mounts up or down
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 13W
Delivered Lumens: 701
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
277V compatible with 0-10V dimmers
ADA compliant
17"
432 mm
4.3"
109 mm
2.1"
53 mm
5"
127 mm
KISDON LARGE SCONCE
P 483
ITEM NUMBER
White Glass/Natural Brass
700WSKISWWNB-LED930 (120V)
700WSKISWWNB-LED930-277 (277V)
White Glass/Polished Nickel
700WSKISWWN-LED930 (120V, )
700WSKISWWN-LED930-277 (277V)
SIZE
H: 16" | W: 5" | D: 3.1"
Mounts up or down
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 12W
Delivered Lumens: 780
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV and Triac
dimmers; 277V compatible with 0-10V dimmers
ADA compliant
.6"
15 mm
3.1"
80 mm
5"
127 mm
4.8"
121 mm
11.4"
290 mm
5.4"
136 mm
16"
406 mm
KLEE SMALL SCONCE
P 462
ITEM NUMBER
Natural Brass/White Marble
700WSKLE20NB-LED930 (120V)
700WSKLE20NB-LED930-277 (277V)
Nightshade Black
700WSKLE20B-LED930 (120V)
700WSKLE20B-LED930-277 (277V)
Polished Nickel/White Marble
700WSKLE20N-LED930 (120V)
700WSKLE20N-LED930-277 (277V)
SIZE
H: 19.5" | W: 4.3" | D: 3.4"
Mounts up or down
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 11.7W
Delivered Lumens: 939
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
277V compatible with 0-10V dimmers
ADA Compliant
5"
127 mm
19.5"
495 mm
4.3"
109 mm
3.4"
86 mm
.8"
20 mm
SCONCE
