731
ASPEN LARGE OUTDOOR WALL
P 460
ITEM NUMBER
Bronze
700OWASP93026DZUNVSLF (No Option)
Charcoal
700OWASP93026DHUNVSLF (No Option)
Natural Brass
700OWASP93026DNBUNVSLF (No Option)
SIZE
H: 26" | W: 5" | D: 2.8"
LAMPING
Integrated LED
Voltage: 120V-277V
Total Watts: 37.9W
Delivered Lumens: 1060
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and 0-10V dimmers
26"
660 mm
5"
127 mm
2.8"
71 mm
ASPEN X-LARGE OUTDOOR WALL
P 460
ITEM NUMBER
Bronze
700OWASP93036DZUNVSLF (No Option)
Charcoal
700OWASP93036DHUNVSLF (No Option)
Natural Brass
700OWASP93036DNBUNVSLF (No Option)
SIZE
H: 36" | W: 5" | D: 2.8"
LAMPING
Integrated LED
Voltage: 120V-277V
Total Watts: 48.1W
Delivered Lumens: 1508
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and 0-10V dimmers
5"
127 mm
2.8"
71 mm
36"
914 mm
BANDA 13 SCONCE/BATH
P 466
ITEM NUMBER
Chrome
700BCBND13C-LED930 (120V)
700BCBND13C-LED930-277 (277V)
Dark Bronze
700BCBND13Z-LED930 (120V)
700BCBND13Z-LED930-277 (277V)
Matte Black
700BCBND13B-LED930 (120V)
700BCBND13B-LED930-277 (277V)
Matte White
700BCBND13W-LED930 (120V)
700BCBND13W-LED930-277 (277V)
Natural Brass
700BCBND13NB-LED930 (120V)
700BCBND13NB-LED930-277 (277V)
SIZE
H: 13" | W: 3" | D: 3.1"
Mounts up or down
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 11.7W
Delivered Lumens: 348
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
277V compatible with 0-10V dimmers
ADA Compliant
Note: Mounts to switch box type j-box. Ships with additional
cover plate for use with standard j-box.
3"
76 mm
3.1"
79 mm
.75"
19 mm
5"
127 mm
3.5"
89 mm
13"
330 mm
CAFÉ SCONCE
P 492
ITEM NUMBER
Walnut/Satin Nickel
700WSCAFEWS-LED930A (120V)
700WSCAFEWS-LED930A-277 (277V)
SIZE
H: 5" | W: 4.2" | D: 3.6"
Mounts horizontal or vertical
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 12W
Delivered Lumens: 255
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV and Triac
dimmers; 277V compatible with 0-10V dimmers
ADA compliant
4.2"
107 mm
3.6"
91 mm
5"
127 mm
COSMO SCONCE
P 482
ITEM NUMBER
Chrome
700WSCOSFC-LED (120V)
700WSCOSFC-LED277 (277V)
Satin Nickel
700WSCOSFS-LED (120V)
700WSCOSFS-LED277 (277V)
SIZE
H: 11.9" | W: 4.7" | D: 3.9"
Mounts up only
LAMPING
Integrated LED
Voltage: 120V or 277V
Total Watts: 10.4W
Delivered Lumens: 274
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV and Triac
dimmers; 277V compatible with 0-10V dimmers
ADA compliant
3.2"
81 mm
11.9"
302 mm
3.9"
99 mm
4.7"
119 mm
SCONCE
