715
WINDSOR PENDANT
P 296
ITEM NUMBER
Black
700TDWDSBB-LED930 (LED E26 Lamp)
700TDWDSBB (No Lamp)
Plated Brass
700TDWDSBRB-LED930 (LED E26 Lamp)
700TDWDSBRB (No Lamp)
SIZE
H: 18" (24.5" min.-90.5" max.) | W: 4.5" | Canopy: 4.5" round
Includes 6 feet of field-cuttable black cloth cord
LAMPING
No Lamp Option
Rated for (1) 60W max E26 med base lamp
LED E26 Med Base PAR20 Lamp
Voltage: 120V
Total Watts: 11W
Delivered Lumens: 550
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
18"
457 mm
4.5"
114 mm
4.5"
114 mm
.34"
9 mm
24.5"-90.5"
622-2299 mm
PENDANTS, LINE VOLTAGE
WIT PENDANT
P 238
ITEM NUMBER
Aged Brass
700TDWIT3R-LED930 (3 Glass)
700TDWIT4R-LED930 (4 Glass)
700TDWIT5R-LED930 (5 Glass)
700TDWIT6R-LED930 (6 Glass)
700TDWIT7R-LED930 (7 Glass)
Black
700TDWIT3B-LED930 (3 Glass)
700TDWIT4B-LED930 (4 Glass)
700TDWIT5B-LED930 (5 Glass)
700TDWIT6B-LED930 (6 Glass)
700TDWIT7B-LED930 (7 Glass)
SIZE
X-Small: H: 27.8" (33.8" min.-87.8" max.) | L: 3.9" |
Canopy: 5.2" round
Small: H: 41.9" (48.6" min.-102.6" max.) | L: 3.9" |
Canopy: 5.2" round
Medium: H: 55.9" (62.7" min.-116.7" max.) | L: 3.9" |
Canopy: 5.2" round
Large: H: 70" (76.7" min.-130.7" max.) | L: 3.9" |
Canopy: 5.2" round
X-Large: H: 84.1" (90.8" min.-144.8" max.) | L: 3.9" |
Canopy: 5.2" round
Includes: (4) 12" and (2) 6" rigid stems
in coordinating finish
Can be installed on a sloped ceiling up to 45°
LAMPING
Integrated LED
Voltage: 24V (120V-277V UNV)
Total Watts: 42.5W | 62.2W | 81.9W | 101.6W | 121.3W
Delivered Lumens: 1706 | 2672 | 3638 | 4604 | 5570
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
T24 Compliant
3.9"
99 mm
84.1"
2136 mm
70"
1778 mm
55.9"
1420 mm
41.9"
1064 mm
27.8"
706 mm
12.5"
318 mm
5.2"
132 mm
4.9"
124 mm
6"
152 mm
1.6"
41 mm
X-SMALL: 33.8" MIN-87.8" MAX DROP
SMALL: 48.6" MIN-102.6" MAX DROP
MEDIUM: 62.67" MIN-116.67" MAX DROP
LARGE: 76.74" MIN-130.74" MAX DROP
X-LARGE: 90.82" MIN-144.82" MAX DROP
WYATT MEDIUM PENDANT
P 229
ITEM NUMBER
Natural Brass
700TDWYT16NB-LED930
Nightshade Black
700TDWYT16B-LED930
SIZE
H: 3.2" (10.3" min.-64.3" max.) | W: 16" | Canopy: 5.4" round
Includes (4) 12" and (2) 6" rigid stems in coordinating finish
LAMPING
Integrated LED
Voltage: 120V-277V
Total Watts: 20W
Delivered Lumens: 960
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV, Triac and 0-10V dimmers
10.3"-64.3"
262-1633 mm
5.4"
136 mm
.9"
23 mm
16"
406 mm
3.2"
80 mm
