713
SEDONA MEDIUM PENDANT
P 303
ITEM NUMBER
Clear/Aged Brass
700TDSDNGPCR-LED927 (LED E26 Lamp)
700TDSDNGPCR (No Lamp)
Clear/Satin Nickel
700TDSDNGPCS-LED927 (LED E26 Lamp)
700TDSDNGPCS (No Lamp)
Transparent Smoke/Aged Brass
700TDSDNGPKR-LED927 (LED E26 Lamp)
700TDSDNGPKR (No Lamp)
Transparent Smoke/Satin Nickel
700TDSDNGPKS-LED927 (LED E26 Lamp)
700TDSDNGPKS (No Lamp)
White/Aged Brass
700TDSDNGPWR-LED927 (LED E26 Lamp)
700TDSDNGPWR (No Lamp)
White/Satin Nickel
700TDSDNGPWS-LED927 (LED E26 Lamp)
700TDSDNGPWS (No Lamp)
SIZE
H: 7.2" (13.7" min.-79.7" max.) | W: 7.5" | Canopy: 4.5" round
Includes 6 feet of field-cuttable black cloth cord
LAMPING
No Lamp Option
Rated for (1) 60W max E26 med base lamp
LED E26 Med Base A21 Lamp (White Glass Only)
Voltage: 120V
Total Watts: 17W
Delivered Lumens: 791
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers.
LED E26 Med Base T14 Lamp (Clear & Smoke Glass Only)
Voltage: 120V
Total Watts: 3.5W
Delivered Lumens: 307
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
7.5"
191 mm
7.2"
183 mm
4.5"
114 mm
.5"
13 mm
13.7"-79.7"
348-2024 mm
SEDONA LARGE PENDANT
P 304
ITEM NUMBER
Clear/Aged Brass
700TDSDNLPCR-LED927 (LED E26 Lamp)
700TDSDNLPCR (No Lamp)
Clear/Satin Nickel
700TDSDNLPCS-LED927 (LED E26 Lamp)
700TDSDNLPCS (No Lamp)
Transparent Smoke/Aged Brass
700TDSDNLPKR-LED927 (LED E26 Lamp)
700TDSDNLPKR (No Lamp)
Transparent Smoke/Satin Nickel
700TDSDNLPKS-LED927 (LED E26 Lamp)
700TDSDNLPKS (No Lamp)
White/Aged Brass
700TDSDNLPWR-LED927 (LED E26 Lamp)
700TDSDNLPWR (No Lamp)
White/Satin Nickel
700TDSDNLPWS-LED927 (LED E26 Lamp)
700TDSDNLPWS (No Lamp)
SIZE
H: 11" (17.1" min.-83.1" max.) | W: 12.4" | Canopy 5" round
Includes 6 feet of field-cuttable black cloth cord
LAMPING
No Lamp Option
Rated for (1) 100W max E26 med base lamp
LED E26 Med Base A21 Lamp (White Glass Only)
Voltage: 120V
Total Watts: 17W
Delivered Lumens: 791
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers.
LED E26 Med Base T14 Lamp (Clear & Smoke Glass Only)
Voltage: 120V
Total Watts: 3.5W
Delivered Lumens: 307
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers.
12.4"
315 mm
11"
279 mm
5"
127 mm
.5"
13 mm
17.1"-83.1"
434-2111 mm
SIGNAL MEDIUM PENDANT
P 289
ITEM NUMBER
Rubberized Gray/Blue
700TDSIGYU-LED927 (LED E26 Lamp)
700TDSIGYU (No Lamp)
Rubberized Gray/Copper
700TDSIGYP-LED927 (LED E26 Lamp)
700TDSIGYP (No Lamp)
Rubberized Gray/Gold
700TDSIGYG-LED927 (LED E26 Lamp)
700TDSIGYG (No Lamp)
Rubberized Gray/Platinum
700TDSIGYL-LED927 (LED E 26 Lamp)
700TDSIGYL (No Lamp)
Rubberized White/Blue
700TDSIGWU-LED927 (LED E26 Lamp)
700TDSIGWU (No Lamp)
Rubberized White/Copper
700TDSIGWP-LED927 (LED E26 Lamp)
700TDSIGWP (No Lamp)
Rubberized White/Gold
700TDSIGWG-LED927 (LED E26 Lamp)
700TDSIGWG (No Lamp)
Rubberized White/Platinum
700TDSIGWL-LED927 (LED E26 Lamp)
700TDSIGWL (No Lamp)
SIZE
H: 14" (20.5" min.-86.5" max.) | W: 6.1" | Canopy: 4.5" round
Includes 6 feet of field-cuttable black/white cloth cord
LAMPING
No Lamp Option
Rated for (1) 75W max E26 med base lamp
LED E26 Med Base A19 Lamp
Voltage: 120V
Total Watts: 9.5W
Delivered Lumens: 400
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
6.1"
155 mm
4.5"
114 mm
.4"
10 mm
14"
356 mm
20.5"-86.5"
521-2197 mm
SIGNAL GRANDE PENDANT
P 290
ITEM NUMBER
Rubberized Gray/Blue
700TDSIGGPYU-LED927 (LED E26 Lamp)
700TDSIGGPYU (No Lamp)
Rubberized Gray/Copper
700TDSIGGPYP-LED927 (LED E26 Lamp)
700TDSIGGPYP (No Lamp)
Rubberized Gray/Gold
700TDSIGGPYG-LED927 (LED E26 Lamp)
700TDSIGGPYG (No Lamp)
Rubberized Gray/Platinum
700TDSIGGPYL-LED927 (LED E26 Lamp)
700TDSIGGPYL (No Lamp)
Rubberized White/Blue
700TDSIGGPWU-LED927 (LED E26 Lamp)
700TDSIGGPWU (No Lamp)
Rubberized White/Platinum
700TDSIGGPWL-LED927 (LED E26 Lamp)
700TDSIGGPWL (No Lamp)
SIZE
H: 20" (26.5" min.-164.5" max.) | W: 17" |
Canopy: 4.5"
Includes 12 feet of field-cuttable black/white cloth cord
LAMPING
No Lamp Option
Rated for (1) 150W max E26 med base lamp
LED E26 Med Base A19 Lamp
Voltage: 120V
Total Watts: 9.5W
Delivered Lumens: 400
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
17"
432 mm
4.5"
114 mm
.4"
10 mm
20"
508 mm
26.5"-164.5"
673-4178 mm
PENDANTS, LINE VOLTAGE
