PRODUCT SPECIFICATIONS
Additional products and options are available at techlighting.com
PALESTRA LARGE PENDANT
P 306
ITEM NUMBER
Natural Brass
700TDPALPOCNB-LED930 (LED E26 Lamp)
700TDPALPOCNB (No Lamp)
Nightshade Black
700TDPALPOCB-LED930 (LED E26 Lamp)
700TDPALPOCB (No Lamp)
Satin Nickel
700TDPALPOCS-LED930 (LED E26 Lamp)
700TDPALPOCS (No Lamp)
SIZE
H: 14.9" (21.4" min.-87.4" max.) | W: 15.5" | Canopy 4.5" round
Black and Brass include 7 feet of field-cuttable black
cloth cord
Satin Nickel ships with 6 feet of field-cuttable satin cable
LAMPING
No Lamp Option
Rated for (1) 100W max E26 med base lamp
LED E26 Med Base G40 Lamp
Voltage: 120V
Total Watts: 11.8W
Delivered Lumens: 1083
CCT: 3000K
CRI: 80
Dimmable with most LED compatible
ELV and Triac dimmers
15.5"
394 mm
14.9"
378 mm
4.5"
114 mm
.5"
13 mm
21.4"-87.4"
544-2220 mm
PALONA LARGE PENDANT
P 314
ITEM NUMBER
Clear/Aged Brass
700TDPLNPCR-LED927 (LED E26 ST19 Lamp)
700TDPLNPCR-LEDWD (Warm Dim)
700TDPLNPCR (No Lamp)
Clear/Satin Nickel
700TDPLNPCS-LED927 (LED E26 ST19 Lamp)
700TDPLNPCS-LEDWD (Warm Dim)
700TDPLNPCS (No Lamp)
Smoke/Aged Brass
700TDPLNPKR-LED927 (LED E26 ST19 Lamp)
700TDPLNPKR-LEDWD (Warm Dim)
700TDPLNPKR (No Lamp)
Smoke/Satin Nickel
700TDPLNPKS-LED927 (LED E26 ST19 Lamp)
700TDPLNPKS-LEDWD (Warm Dim)
White/Aged Brass
700TDPLNPKR-LED927 (LED E26 ST19 Lamp)
700TDPLNPKR (No Lamp)
700TDPLNPKS (No Lamp)
White/Satin Nickel
700TDPLNPKS-LED927 (LED E26 ST19 Lamp)
700TDPLNPKS (No Lamp)
SIZE
H: 13.5" (20" min.-86" max.) | W: 14" | Canopy: 4.5" round
Includes 7 feet of field-cuttable satin cable
LAMPING
No Lamp Option
Rated for (1) 60W max E26 med base lamp
LED E26 Med Base A19 Lamp (White Only)
Voltage: 120V
Total Watts: 9.5W
Delivered Lumens: 800
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
LED E26 Med Base ST19 Lamp
(Clear & Smoke Only)
Voltage: 120V
Total Watts: 3.5W
Delivered Lumens: 250
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
Integrated LED Warm Color Dimming
(Clear & Smoke Only)
Voltage: 120V
Total Watts: 9W
Delivered Lumens: 684
CCT: 3000K - 2200K Warm Color Dimming
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
14"
356 mm
13.5"
343 mm
4.5"
114 mm
.5"
13 mm
20"-86"
508-2184 mm
PENDANTS, LINE VOLTAGE
