701
HANEA GRANDE PENDANT
P 310
ITEM NUMBER
Chrome
700TDHNE13C-LED930
Natural Brass
700TDHNE13NB-LED930
Nightshade Black
700TDHNE13B-LED930
SIZE
H: 14" (21.7" min.-159.7" max.) | W: 13.7" | Canopy: 6.5" round
Includes 12 feet of field-cuttable black cloth cord
Can be installed on a sloped ceiling up to 45°
LAMPING
Integrated LED
Voltage: 120V
Total Watts: 33.9W
Delivered Lumens: 1539
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
13.7"
348 mm
14"
356 mm
6.5"
165 mm
1.7"
43 mm
21.7"-159.7"
551-4056 mm
HANEA X-LARGE PENDANT
P 312
ITEM NUMBER
Chrome
700TDHNE18C-LED930
Natural Brass
700TDHNE18NB-LED930
Nightshade Black
700TDHNE18B-LED930
SIZE
H: 18" | W: 18" | Canopy 7.8" round
Includes 12 feet of field-cuttable black cloth cord
LAMPING
Integrated LED
Voltage: 120V
Total Watts: 40W
Delivered Lumens: 2540
CCT: 3000K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
18.7"-162.7"
44-413 mm
7.8"
200 mm
18"
457 mm
2.2"
41 mm
HARPER PENDANT
P 334
ITEM NUMBER
Clear/Black
700TDHARPCB-LED927 (LED E26 Lamp)
700TDHARPCB (No Lamp)
Clear/Natural Brass
700TDHARPCNB-LED927 (LED E26 Lamp)
700TDHARPCNB (No Lamp)
Clear/Satin Nickel
700TDHARPCS-LED927 (LED E26 Lamp)
700TDHARPCS (No Lamp)
Smoke/Black
700TDHARPKB-LED927 (LED E26 Lamp)
700TDHARPKB (No Lamp)
Smoke/Satin Nickel
700TDHARPKS-LED927 (LED E26 Lamp)
700TDHARPKS (No Lamp)
SIZE
H: 20.3" (26.8" min.-92.8" max.) | W: 16" | Canopy: 4.5" round
Includes 7 feet of field-cuttable cable
Can be installed on a sloped ceiling up to 45°
LAMPING
No Lamp Option
Rated for (1) 60W max E26 med base lamp
LED E26 Med Base ST19 Lamp
Voltage: 120V
Total Watts: 3.5W
Delivered Lumens: 263
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
16"
406 mm
20.3"
516 mm
4.5"
114 mm
.5"
13 mm
26.8"-92.8"
681-2357 mm
HENLEY PENDANT
P 280
ITEM NUMBER
Textured Black/Black
700TDHNLPBB-LED927 (LED E26 Lamp)
700TDHNLPBB (No Lamp)
SIZE
H: 11" (17.5" min.-83.5" max.) | W: 18" | Canopy: 4.5" round
Includes 6 feet of field-cuttable cloth cord
to match finish selection
Can be installed on a sloped ceiling up to 45°
LAMPING
No Lamp Option
Rated for (1) 75W max E26 med base lamp
LED E26 Med Base A21 Lamp
Voltage: 120V
Total Watts: 17W
Delivered Lumens: 840
CCT: 2700K
CRI: 90
Dimmable with most LED compatible
ELV and Triac dimmers
18"
457 mm
11"
279 mm
4.5"
114 mm
.5"
13 mm
17.5"-83.5"
445-2121 mm
PENDANTS, LINE VOLTAGE
