685
BRUMMEL MINI PENDANT
P 272
ITEM NUMBER
TYPE
SYSTEM
MODEL
COLOR
FINISH
LAMP
700
FJ
FREEJACK
KL
KABLE LITE
MP MONOPOINT
MO MONORAIL
BML
BRUMMEL
Y
MATTE CHARCOAL
GRAY
W MATTE WHITE
C
CHROME
S
SATIN NICKEL
Z
ANTIQUE
BRONZE
-LEDS930 LED, 90 CRI, 3000K, 12V
NO LAMP (LEAVE BLANK)
MP INCLUDES 4 INCH ROUND FLUSH CANOPY.
ANTIQUE BRASS IS NOT AVAILABLE FOR KABLE LITE.
CHROME NO OFFERED ON MONORAIL.
SIZE
H: 5.6" (12.1" min.-78.1" max.) | W: 10.5" | Canopy: 4.5" round
Includes 6 feet of field-cuttable cable
to match finish selection
LAMPING
No Lamp Option
Rated for (1) 50 watt max. bi-pin lamp
LED GY6.35 Bi-Pin Base Lamp
Voltage: 12V
Total Watts: 6W
Delivered Lumens: 275
CCT: 3000K
CRI: 90
Dimmable with most LED compatible ELV and
MLV dimmers (based on transformer)
10.5"
267 mm
5.6"
127 mm
4.5"
114 mm
.5"
13 mm
12.1"-78.1"
307-1984 mm
CAPTRA PENDANT
P 244
ITEM NUMBER
TYPE
SYSTEM
MODEL
COLOR
FINISH
LAMP
700
FJ
FREEJACK
MP MONOPOINT
MO MONORAIL
CPT
CAPTRA
C
CLEAR
R AGED BRASS
S SATIN NICKEL
-LED930
LED, 90 CRI, 3000K, 12V
NO LAMP (LEAVE BLANK)
NOTE: MP INCLUDES 4 INCH ROUND FLUSH CANOPY.
SIZE
H: 14" (20.5" min.-86.5" max.) | W: 3" Canopy: 4.5" round
Includes 6 feet of field-cuttable cable
to match finish selection
LAMPING
No Lamp Option
Rated for (1) 35 watt max GU5.3 bi-pin lamp
LED GU5.3 Bi-Pin Base MR16
Voltage: 12V
Total Watts: 6.5W
Delivered Lumens: 485
CCT: 3000K
CRI: 90
Dimmable with ELV or MLV dimmers
(based on transformer)
14"
356 mm
3"
76 mm
4.5"
114 mm
.5"
13 mm
20.5"-86.5"
521-2197 mm
ECHO MINI PENDANT
P 318
ITEM NUMBER
TYPE
SYSTEM
MODEL
COLOR
FINISH
LAMP
700
FJ
FREEJACK
MP MONOPOINT
MO MONORAIL
ECP
ECHO
C
CLEAR
S
SMOKE
U
STEEL BLUE
Z ANTIQUE
BRONZE
C CHROME
S SATIN NICKEL
-LEDS930 LED, 90 CRI, 3000K, 12V
HALOGEN, 12V (LEAVE BLANK)
NOTE: MP INCLUDES 4 INCH ROUND FLUSH CANOPY.
CHROME NOT OFFERED ON MONORAIL.
SIZE
H: 7" (13.5" min.-79.5" max.) | W: 4" | 4.5" round
Includes 6 feet of field-cuttable cable
to match finish selection
LAMPING
GY6.35 Bi-Pin Base Halogen Lamp
Voltage: 12V or 24V
Total Watts: 50W
Delivered Lumens: 558
Dimmable with ELV or MLV dimmers
(based on transformer)
LED GY6.35 Bi-Pin Base Lamp
Voltage: 12V
Total Watts: 6W
Delivered Lumens: 361
CCT: 3000K
CRI: 90
Dimmable with ELV or MLV dimmers
(based on transformer)
4"
102 mm
7"
178 mm
4.5"
114 mm
.5"
13 mm
13.5"-79.5"
343-2019 mm
ELLA MINI PENDANT
P 345
ITEM NUMBER
TYPE
SYSTEM
MODEL
COLOR
FINISH
LAMP
700
FJ
FREEJACK
KL
KABLE LITE
MP MONOPOINT
MO MONORAIL
ELA
ELLA
C
CLEAR
K
SMOKE
Z ANTIQUE
BRONZE
S SATIN NICKEL
-LEDS930 LED, 90 CRI, 3000K, 12V
HALOGEN, 12V (LEAVE BLANK)
NOTE: MP INCLUDES 4" ROUND FLUSH CANOPY.
ANTIQUE BRONZE IS NOT AVAILABLE FOR KABLE LITE.
SIZE
H: 7" (13.5" min.-79.5" max.) | W: 5" | Canopy: 4.5" round
Includes 6 feet of field-cuttable cable
to match finish selection
LAMPING
GY6.35 Bi-Pin Base Halogen Lamp
Voltage: 12V or 24V
Total Watts: 35W
Delivered Lumens: 360
Dimmable with ELV or MLV dimmers
(based on transformer)
LED GY6.35 Bi-Pin Base Lamp
Voltage: 12V
Total Watts: 5W
Delivered Lumens: 258
CCT: 3000K
CRI: 90
Dimmable with ELV or MLV dimmers
(based on transformer)
7"
178 mm
5"
127 mm
4.5"
114 mm
.5"
13 mm
PENDANTS, LOW VOLTAGE
