CEILING FANS
DISCUS CLASSIC 44 LED
DISCUS CLASSIC 44 LED
LED
BLADES
(5) Blades (Included)
12° Blade Pitch
44" Blade Sweep
BLADE MATERIAL
Plywood
LAMPING
Integrated LED: 20W
Light Output: 1060 Lumens Net
CCT: 3000K
CRI: 90+
Optional MC360 Finishing Cap Available (pg. 402)
MOUNTING
Maximum Slope Angle with
Included Hardware: 30°
Dual Mount allowing downrod and flush mounting
INCLUDED CONTROLS
Pull Chain Operation, 3-speed,
Manual Reverse Switch
COMPATIBLE ACCESSORIES
Slope Ceiling Canopy Kits MC95 & MC93 (pg. 400)
See Control Compatibility Charts (pg. 397 & 399)
FAN SPECIFICATIONS
A
B
C
D
A. Fixture Drop: 15.1"
B. Blade Drop: 10.6"
C. Housing Width: 11.1"
D. Downrod: 4.5" (additional lengths pg. 401)
Motor Size: 153mm x 18mm
FTC ENERGY GUIDE
FTC ENERGY GUIDE
STANDARD
HIGH SPEED
WEIGHTED
AVERAGE
ELECTRICITY
58 Watts
37 Watts
AIRFLOW
3954 CFM
2850 CFM
ENERGY COSTS
N/A
$10 Per Year
EFFICIENCY
68 CFM/Watt
77 CFM/Watt
HUGGER
HIGH SPEED
WEIGHTED
AVERAGE
ELECTRICITY
58 Watts
37 Watts
AIRFLOW
3020 CFM
1970 CFM
ENERGY COSTS
N/A
$10 Per Year
EFFICIENCY
52 CFM/Watt
53 CFM/Watt
REV
5DIC44RBD-V1
Roman Bronze Housing
Bronze/American Walnut Reversible Blades
Matte Opal Glass
REV
5DIC44BSD-V1
Brushed Steel Housing
Silver/American Walnut Reversible Blades
Matte Opal Glass
REV
5DIC44PND-V1
Polished Nickel Housing
Silver/American Walnut Reversible Blades
Matte Opal Glass
5DIC44AGPD-V1
Aged Pewter Housing
Light Grey Weathered Oak Blades
Matte Opal Glass
5DIC44BKD-V1
Matte Black Housing
Matte Black Blades
Matte Opal Glass
5DIC44WHD-V1
White Housing
White Blades
Matte Opal Glass
379
