LAMPING
No Lamp Option
Rated for (1) 35 watt max. bi-pin lamp
LED GU5.3 Bi-Pin Base MR16
Warm Color Dimming Lamp
Voltage: 12V
Total Watts: 6.5W
Delivered Lumens: 485
CCT: 3000K
CRI: 90
Dimmable with low-voltage electronic or
magnetic dimmer (based on transformer).
4.1"
104 mm
8"
203 mm
4.4"
111 mm
.4"
11 mm
SIZE
H: 8" | W: 4.1"
Includes 6 feet of field-cuttable satin cable.
SERIES
SYSTEM
PRODUCT
SHADE COLOR (OUTER | INNER)
HARDWARE FINISH
LAMP
700
FJ FREEJACK
MP MONOPOINT*
MO MONORAIL
SIGM
YU RUBBERIZED GRAY | BLUE
YG RUBBERIZED GRAY | GOLD
YL RUBBERIZED GRAY | PLATINUM
WU RUBBERIZED WHITE | BLUE
WG RUBBERIZED WHITE | GOLD
WL RUBBERIZED WHITE | PLATINUM
S
SATIN NICKEL
NO LAMP
-LED930 LED BI-PIN 12 VOLT
MR16 90 CRI 3000K
ORDERING GRID
SIGNAL
*INCLUDES 4.4" ROUND FLUSH CANOPY IN SATIN NICKEL
