94
Product specifications subject to change without notice. Please check vibia.com for updated information.
Floor
1329
Ø 25 x 190 cm
1329
Control
Packaging
2 Boxes
Total Vol 0,1880 m3
Gross weight 19,8 Kg Net weight 15 Kg
Materials
Body: PU- Polyurethane.
Diffuser: PC- Polycarbonate.
Light Source and electronics
1 x LED 37,2W 1050 mA
Constant Current 1050 mA
100~240Vac 50/60Hz
Ø 25 cm
190 cm
Ø 26 cm
Finishes
10 White
(NCS S 0300-N)
25 Beige D1
(NCS S 4005-Y50R)
45 Blue D1
(NCS S 7010-B10G)
LED Colour Temperature
/1 _ 2700 K - 3736 lm
E
CRI >90
1329 _ _ / _ _
_ _ / 15 Push
_ _ / 1Z Casambi
_ _ / 1Y ProtoPixel*
IP20
Undulating and fluid, Jazz’s smooth silhouette
is strikingly organic. The gently curved design
imparts a playful presence, like an oversized
chess piece standing guard.
Design by Diego Fortunato
Jazz
Notes
ProtoPixel products are compatible with
all other DALI-2 products via a designated
gateway (please consult us).
*Available from January 2025.
Dimmer on the cable. Electric cable 2,5 m.
