73
VIBIA Price list July 2024
Adjust height of standard model
To personalize luminaire height,
without adjusting diffusers layout.
The steel cables that go from the structure to the ceiling
are the only ones that allow the height of the lamp to be
adjusted. The installation manual describes how to do this
and how to cut the cables.
Personalise your own
Algorithm composition
quick and easy at
vibia.com
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
Ø 10,5 cm
IP20
LED
Bi-volt
0825
0827
Finishes
18/ _ _ Graphite
(ADAPTA RF9913WX)
Finishes
18/ _ _ Graphite
(ADAPTA RF9913WX)
Control
Control
Packaging
2 Boxes
Total Vol 0,324 m3
Gross weight 15,5 Kg Net weight 10,5 Kg
Packaging
2 Boxes
Total Vol 0,324 m3
Gross weight 15,5 Kg Net weight 10,5 Kg
Materials
Sphere: Blown-glass. Diffuser: PC- Polycarbonate.
Glass fastening: Aluminum. Canopy: Steel.
Pendant structure: Steel. LED support: Aluminum.
Materials
Sphere: Blown-glass. Diffuser: PC- Polycarbonate.
Glass fastening: Aluminum. Canopy: Steel.
Pendant structure: Steel. LED support: Aluminum.
Light Source and electronics
10 x LED 3,15 W 1050 mA
Constant Current 1050 mA
100~240V 50/60Hz
Light Source and electronics
10 x LED 3,15 W 1050 mA
Constant Current 1050 mA
100~240V 50/60Hz
39 cm
4 cm
84 cm
max. 200 cm
min. 16 cm
120 cm
Ø 9 cm
75 cm
Ø 19 cm
39 cm
84 cm
max. 200 cm
min. 16 cm
120 cm
Ø 9 cm
75 cm
Ø 11,5 cm
Notes
Surface
Notes
Built-in
LED Colour Temperature
/1 _ 2700 K - 3122,8 lm
/2 _ 3000 K - 3122,8 lm
F
CRI >90
LED Colour Temperature
/1 _ 2700 K - 3122,8 lm
/2 _ 3000 K - 3122,8 lm
F
CRI >90
0825 _ _ / _ _
_ _ / _ A Push; 1-10V; DALI-2
_ _ / _ Z Casambi
0827 _ _ / _ _
_ _ / _ A Push; 1-10V; DALI-2
_ _ / _ Z Casambi
Bi-volt
IP20
LED
Only orders by www.vibia.com or e-mail will be accepted.
