201 cm
3 cm
2 cm
max. 300 cm
7363
7364
UGR <19
482
Product specifications subject to change without notice. Please check vibia.com for updated information.
Finishes
11/ _ _ Black
(NCS S 8500-N)
Control
Materials
Stick: Aluminium.
Diffuser: PC - Polycarbonate.
Light Source and electronics
1 x LED PLATE 35,2 W 24V
Constant voltage 24V
90~305Vac 50/60Hz
7363
Packaging
1 Tube 0,07 x 0,07 x 2,240 m
Vol 0,011 m3
1 Box 0,12 x 0,12 x 0,48 m
Vol 0,007 m3
Gross weight 5,3 Kg Net weight 3,7 Kg
IP20
LED
Dimmer
Multi-volt
LED Colour Temperature
/1 _ 2700 K - 4347 lm
/2 _ 3000 K - 4682 lm
/3 _ 3500 K - 4734 lm
F
CRI >90
7363 11 / _ _
_ _ / _ 1 DALI-2
_ _ / _ 3 1-10V
_ _ / _ Z Casambi
Select Eletrical connection
Finishes
11/ _ _ Black
(NCS S 8500-N)
Control
Materials
Stick: Aluminium.
Diffuser: PC - Polycarbonate.
Light Source and electronics
1 x LED PLATE 35,2 W 24V
Constant voltage 24V
90~305Vac 50/60Hz
7364
Packaging
1 Tube 0,07 x 0,07 x 2,240 m
Vol 0,011 m3
1 Box 0,12 x 0,12 x 0,48 m
Vol 0,007 m3
Gross weight 5,3 Kg Net weight 3,7 Kg
IP20
LED
Dimmer
Multi-volt
LED Colour Temperature
/1 _ 2700 K - 4347 lm
/2 _ 3000 K - 4682 lm
/3 _ 3500 K - 4734 lm
F
CRI >90
7364 11 / _ _
_ _ / _ 1 DALI-2
_ _ / _ 3 1-10V
_ _ / _ Z Casambi
Select Eletrical connection
Sticks Solo
_10 Surface
_24 Built-in
Disc S
_31 Remote
Micro
_32 Remote
XXS
_10 Surface
_24 Built-in
Disc S
_31 Remote
Micro
_32 Remote
XXS
Built-in
Disc S
Remote
Micro
Surface
Remote
XXS
Built-in
Disc S
Remote
Micro
Surface
Remote
XXS
