Bind Solo
Finishes
11/ _ _ Black
(NCS S 8500-N)
24/ _ _ Beige M1
(NCS S 2005-Y50R)
Control
Packaging
1 Box 0,065 x 0,145 x 0,275 m
Vol 0,0026 m3
Gross weight 0, 72 Kg Net weight 0,24 Kg
Materials
Body: Aluminum.
Lens: PMMA.
Light Source and electronics
2700 K - 3000 K - 3500K:
1 x LED 5,2 W 300 mA
Constant Current 300 mA
220~240V 50/60Hz
Tunable White:
1 x LED 5,5 W 150 mA
Constant Current 150 mA
110~240V 50/60Hz
6668 Wide
IP20
LED
LED Colour Temperature
Static White
/1 _ 2700 K - 530 lm
/2 _ 3000 K - 554 lm
/3 _ 3500 K - 574 lm
Tunable White
/8 _ (1800 K - 4000 K)
308 lm - 504 lm
F
CRI >90
ø 0,38 m
1574 lx
Ø 0,75 m
393 lx
16°
ø 0,38 m
Ø 0,75 m
ø 0,95 m
335 lx
Ø
1,9 m
90 lx
35°
ø 0,95 m
Ø 1,9 m
ø 1,45 m
163 lx
Ø 2,9 m
41 lx
52°
ø 1,45 m
Ø 2,9 m
H = 1,5 m
H = 3 m
Wide
Medium
Narrow
Notes
DALI-2 products are compatible (via a designated
gateway) with all ProtoPixel dynamic-light
solution products.
Visit vibia.com to group several pieces with just one
electrical point, only for Static White.
6668 _ _ / _ _
_ _ / _ 0 Static White +
On/ Off (Remote)
_ _ / _ D Static White +
Push; DALI-2 (Remote)
_ _ / _ M Static White +
Without driver
_ _ / _ Z Static White +
Casambi (Remote)
_ _ / 81
Tunable White +
DALI-2 DT8 (Remote)
_ _ / 8M Tunable White +
Without driver
_ _ / 8Z Tunable White +
Casambi (Remote)
